Product name

   Dimensions

 Length:55.0mm, Width: 39.2mm, Height:51.2mm

   Weight

 65grams

   Electrical

 Power: DC5V Typical: 300mA DC5V

   CPU

 32bit ARM CPU

   Data storage

 100KB for offline mode: 6000 15 bytes barcodes(Other flash is optional).

   Working mode

 Bluetooth mode, offline mode and RS232 mode(optional)

   Scan mode

 Laser

   Ambient illumination

Tolerant to typical artificial indoor and natural outdoor (direct sunlight) lighting conditions. Fluorescent, Incandescent, Mercury Vapor, Sodium Vapor, LED : 450 Ft
Candles (4,844 Lux) Sunlight: 8000 Ft Candles (86,111 Lux)

   Scanner performance

Sensor Type: Laser Diode 650nm
Scanner Angle: ±40°,±65°,±35°(skew, pitch, Roll)
Scan Rate: 104(±12)scans/sec(bidirectional)
Contrast: ≥25%
Decode Speed:104 scans per second

   Battery power

Internal Battery: Rechargeable550mAh Li-ion Battery, Standby30days,working time after full charge with good decode as below:

  Charge time: about 2 hours

   Barcode Type

UPC-A, UPC-E, UPC-E1, EAN-8/JAN-8, EAN-13/JAN-13, Bookland EAN, ISSN EAN,Code 128,

GS1-128(formerly UCC/EAN-128), ISBT 128, Check ISBT Table, Code 128 Reduced Quiet Zone, Code 39,

Trioptic Code 39, Convert Code 39 to Code 32, Code 32 Prefix, Code 39 Check Digit Verification, Code

39 Full ASCII, Code 39 Reduced Quiet Zone, Code 93, Code 11, Interleaved 2 of 5, I 2 of 5 Readuced

Quiet Zone, Discrete 2 of5, Codabar(NW-7), CLSI Editing, NOTIS Editing, MSI, Chinese 2 of 5, Matrix

2 of 5, GS1 DataBar-14, GS1 DataBar Limited, GS1 DataBar Expanded, Convert GS1 DataBar to

UPC/EAN/JAN, Composite CC-C, Composite CC-A/B, Composite TLC-39, GS1-128 , Emulation Mode for

UCC/EAN Composite Codes

  Decoding depth &

Max. Resolution

(1 mil = 0.0254 mm)

   Code 39

51mm -162mm (5mil);

   Code 128

63mm -127mm (5mil);

PDF417

63mm -160mm (6.6mil);

PDF417

45mm - 228mm (10mil);

100%UPC

50mm -317mm (13mil);

Code 39

50mm - 495mm (20mil);

Data Matrix

38mm - 343mm (20mil);

QR Code

38mm -279mm (20mil)

  Communication

  Class 3 Bluetooth HID, SPP, BLE(optional) with 30M distance,  RS232 cable(optional)

  OS

  IOS, Android, Windows, Mac

  Certificate

  CE, Rohs, FCC, EN60950, IEC60825, IP65, EMC, 1.5m drop test(200 times).

Utility Model Patent No.: ZL201420211350.8

  Laser safety

  IEC60825-1-2007, Class 1

  Temperature

  Operating: -20°C to 60°C (-4°F to 140°F);

  Storage: -40°C to 70°C (-40°F to 158°F)

  Humidity

  5% to 90% (non-condensing)

  Accessories

  1× EF02

  1× 3.7V 15320 Li-ion battery

  1× Velcro

  1× Silicone Case

  1× Charger cabale(optional)

  Barcode scanner charger & Bluetooth adapter

 Product name

  Barcode scanner charger & Bluetooth adapter(optional)

 Model name

  BFP1

 Dimensions

  72.0mm L × 56.0mm W × 40.3mm H

 Weight

  50grams

 Power

  DC:5V/500mA

 Charge current

  250mA

  Interface

  1×Type-C(For charge or data transmission):5V DC

  2×DC jack(optional): 5V DC

  Characteristic

1. It can charge both batteries and machines at the same time.

  2. The charger can be multiple connected(optional). (In order to ensure charging efficiency, it is recommended that no more than 5 chargers be connected.)

  Adapter Working mod

  HID keyboard,Virtual Serial Port , RS-232(optional)
