Product Overview
DA5KM37E-70C-14RC Charger + DC-DC Converter
DA5KM37E-70C-14RC is a forced air-cooled, specifically designed for pure electric vehicles, chargers and DC / DC converters integrated in one digital power supply. Charger adopts advanced resonance technology, high efficiency, high power, small size, reliable work, charging mode using constant power and constant voltage automatic state transition, effectively saving the charging time. Wide input and output voltage range with active power factor correction, zero pollution to the grid. Using CAN2.0B communication protocol, with intelligent charging function, intelligent monitoring fault alarm, protection, with remote detection, programming, fault inquiry and other functions. Built-in 14V battery management system wake-up signal power. DC / DC high and low voltage converter using advanced substrate technology, modular design, high power density, small size, reliable, with constant current and constant pressure automatic state conversion. Using CAN2.0B communication protocol (CAN communication function optional), with intelligent charging function, with intelligent monitoring fault alarm, protection (with CAN communication function).
The power supply is specially designed for high voltage battery charging and buck conversion of new energy vehicles. Reduce the number of vehicle wiring harness connector and split the power supply installation of the trouble, the power supply using air-cooled design, and world-class automotive power supply manufacturers fully synchronized, is the world's highest power density products, the performance indicators have reached or exceeded the international counterparts Horizontal, trouble-free operation longer.
The power supply is specially designed for high voltage battery charging and buck conversion of new energy vehicles. Reduce the number of vehicle wiring harness connector and split the power supply installation of the trouble, the power supply using air-cooled design, and world-class automotive power supply manufacturers fully synchronized, is the world's highest power density products, the performance indicators have reached or exceeded the international counterparts Horizontal, trouble-free operation longer.
FEATURES AT A GLANCE
OBC part
Constant power and constant voltage state
Constant power and constant voltage state
Active power factor correction≥0.99
Input over/under-voltage protection
Output over/under-voltage protection
Output over-current protection
Output short circuit protection
Output reverse connection protection
Over temperature protection
CAN communication intelligent fault alarm and protection function
Small volume, large power density
DC-DC part
Constant current and constant voltage automatic conversion, effectively save charging time
Input over/under-voltage protection
Output over-voltage protection
Output over-current protection
Output short circuit protection
Over temperature protection
CAN communication intelligent fault alarm and protection function
Small volume, large power density
Intelligent charge control function
Output over-voltage protection
Output over-current protection
Output short circuit protection
Over temperature protection
CAN communication intelligent fault alarm and protection function
Small volume, large power density
Intelligent charge control function
Side elevation
Front elevation
Back elevation
PRODUCT SPECIFICATIONS
No | OBC part | Data | DC-DC part | Data |
1 | Power | 3300W | Power | 1200W |
2 | Input | 220Vac 47~63Hz | Input | 50Vdc to 90Vdc |
3 | HV Output | 72Vdc | LV Output | 14Vdc |
4 | Output Voltage Range | 50V to 90V | Output Current | 57A |
5 | Max Output Current | 35A | Efficiency | ≥90% |
6 | Efficiency | ≥92% | Control | CAN or Enable |
7 | Control | CAN | Cooling | Air-cooled |
8 | CAN Communication | 125kbps/250kbps/500kbps |
SIMILAR PRODUCTS
Certifications
Company Profile
Company Profile
Shijiazhuang Dilong Technology Co.,ltd was established in 2000. The factory area is up to 100,000 square meter. Headquarter is in Shijiazhuang,Hebei. We also have branch offices in Beijing, Shanghai, Shenzhen, Chengdu and Wuhan. We are professional and leading manufacturer of new energy vehicle power supply, military power supply and industrial power supply in China.
Full-automatic placing and welding technology, fully digital resonant frequency modulation technology, full-automatic testing equipment and burn-in technology all gurantee the supply ability of 100,000 sets per month with high quality.
Under strictly quality control system, our products have matched the standard of ISO9001, ISO/TS16949: 2009, CE and ROHS, meeting requirement of different customers.
Supported by experienced R&D team, with the strong ability of R&D, production and sales, Dilong’s domestic and internatinal market is expanding increasingly. Our customers include BYD, BAIC BJEV, GEELY AUTO, Chery, etc.
Welcome to visit our factory.
Full-automatic placing and welding technology, fully digital resonant frequency modulation technology, full-automatic testing equipment and burn-in technology all gurantee the supply ability of 100,000 sets per month with high quality.
Under strictly quality control system, our products have matched the standard of ISO9001, ISO/TS16949: 2009, CE and ROHS, meeting requirement of different customers.
Supported by experienced R&D team, with the strong ability of R&D, production and sales, Dilong’s domestic and internatinal market is expanding increasingly. Our customers include BYD, BAIC BJEV, GEELY AUTO, Chery, etc.
Welcome to visit our factory.
FAQ
Q: Are you trading company or manufacturer ?
A: We are manufacturer.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 20-30 days if the goods are not in stock, it is according to
quantity.
Q: What is the key technical advantage of your products?
A: We adopt the digital control technology, which is convenient for remote upgrade and full automatic production.
Q: What is your Engineering Testing and Validation capabilities?
A:We will response you within 2 hours and solve the problem within 24 hours.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
A: We are manufacturer.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 20-30 days if the goods are not in stock, it is according to
quantity.
Q: What is the key technical advantage of your products?
A: We adopt the digital control technology, which is convenient for remote upgrade and full automatic production.
Q: What is your Engineering Testing and Validation capabilities?
A:We will response you within 2 hours and solve the problem within 24 hours.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
