Автомобильные детали распылительная камера автомобильная для распыления краски с

auto spray booth  spraybooth  car painting booth auto spray booth  car painting oven vehicle baking room

Outside dimension:7000×5550×3300mm (L×W×H)

Inside dimension: 6900*3900*2650(mm)(L*W*H)

Front door dimension: 2830*2600(mm)(W*H)

Working door dimension: 700*1700mm(W*H)

Cabin system:

1) Wall panel: 50mm thick flame-resistant and heat-preserving Rock wool board; 0.476 thick colored steel.

Roof panel: galvanized sheet;

2) Basement: steel structure base; two line grilles, three diamond plates; inside ramps; height is 280mm;.

Air circulation system:

One set automatic damper, 10N actuator

Generator: slid upward side intake air; rare upward side exhaust; quadrate steel frame;

Air purification system: Pre-filter, high efficiency filter (ceiling filter), floor filter;.

Heat system: 30pcs infrared carbon fiber heating lamps, 1000w/piece.
The operating temperature:50℃-70℃.Max. temperature:80℃

Lighting system:≥700Lux

Ceiling Lights: 8Groupsx3Pcs=24Pcs x36W

Glass: all glass is clear tempered glass.

Control box: Lighting switch, spraying, risen-temperature spraying, baking, baking temperature, time setting, failure indicator, temperature controller, emergency stop, breakdown alarm;

Total power: 44KW
