Индивидуальный литий-ионный аккумулятор 24 В 36 48 60 в 72 10 Ач 20 40 для электровелосипеда с BMS + зарядным
- Категории: Batteries >>>
- Поставщик: Dongguan,Chuangnengda,New,Energy,Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
Product Description
The battery pack can be customized according to customer requirements, please contact the store customer service.
Specifications
Model: AED-361160
Cell type: AED-29P(MG1 2.9Ah)
Cell count: 40 pieces(10S4P)
Nominal voltage: 36V
Charge voltage: 42V
Typical capacity: 11.6Ah/417Wh
Minimum capacity: 10.5/378Wh
Rated power: 750Watt
BMS rated current: 25A discharge and 5A charge
BMS function:Overcharge, overdischarge, overcurrent, short circuit protection.
Connector: XT60 for discharge and DC5521 for charge
Package: heat shrinkable PVC, random color
Output voltage range: 28V-42V
Discharge cut-off voltage: 28V
Charge cut-off voltage: 42V
Charge method: CC-CV
Max. Charge current: 5A
Charge temperature: 0-45 ° C
Discharge temperature: -10-60 ℃
Storage temperature: -20-45 ° C (3 months)
Cycle life: 80% DOD after 500 cycles
Size: 185 * 80 * 70 mm(±3mm)
Weight: 1900g(±50g)
Warranty
- Period: 1year
- Coverage: Cells, other part are not covered by the warranty.
- Ingress of water, disassembly, modification, No use Match charger,Short circuit, failure due to personal reasons, etc., are not covered by the warranty.
- Treatment method: Send the replacement part to the buyer for replacement,Or communicate the appropriate solution with the seller.
Application
Suitable for less than 750W all 36V DC equipment. E-bike, scooters, etc.
About shipping
The default product is sent within 72 hours and the customized product is sent within the delivery period.
Shipping reference time,
PostNL: 15-45 working days,DDU,Air transport
China Post: 20-60 working days,DDU,Train transportation
Seller's Shipping Method :The seller uses different logistics methods according to different regions. DDU or DDP. 15-60 working days. Air or Train.
UPS:7-25 working days, DDP,Air transport
FedEx:7-25 working days ,DDP,Air transport
Shipping list:
1 battery pack
Warning
Battery is a dangerous product. Before purchasing, please make sure that you understand the relevant knowledge of the lithium battery, and you can safely complete the installation of the battery pack or have a professional person assist in the installation. Improper operation may cause safety accidents, such as fire, explosion or equipment damage etc.. Please take all necessary precautions when using the battery.
Note:
*The default price does not include duty and tax,Except for special instructions.
* The weight of postal packages is limited to 2 kg. If you buy multiple products and the total weight exceeds 2 kg, it will be sent in multiple packages
* The weight and size data are obtained by manual measurement and may be subject to deviation.
* The performance parameter data comes from the CHUANGNDA laboratory. The actual test results will be affected by the test conditions (such as temperature, wire loss, test equipment accuracy, test parameters, etc.). Please perform multiple tests and take the average of the results to reduce the deviation.
The temperature is 25 degrees Celsius, and the deviation between the pure resistance discharge test results within the performance parameters and the description data is within 10%.
Specifications
Model: AED-361160
Cell type: AED-29P(MG1 2.9Ah)
Cell count: 40 pieces(10S4P)
Nominal voltage: 36V
Charge voltage: 42V
Typical capacity: 11.6Ah/417Wh
Minimum capacity: 10.5/378Wh
Rated power: 750Watt
BMS rated current: 25A discharge and 5A charge
BMS function:Overcharge, overdischarge, overcurrent, short circuit protection.
Connector: XT60 for discharge and DC5521 for charge
Package: heat shrinkable PVC, random color
Output voltage range: 28V-42V
Discharge cut-off voltage: 28V
Charge cut-off voltage: 42V
Charge method: CC-CV
Max. Charge current: 5A
Charge temperature: 0-45 ° C
Discharge temperature: -10-60 ℃
Storage temperature: -20-45 ° C (3 months)
Cycle life: 80% DOD after 500 cycles
Size: 185 * 80 * 70 mm(±3mm)
Weight: 1900g(±50g)
Warranty
- Period: 1year
- Coverage: Cells, other part are not covered by the warranty.
- Ingress of water, disassembly, modification, No use Match charger,Short circuit, failure due to personal reasons, etc., are not covered by the warranty.
- Treatment method: Send the replacement part to the buyer for replacement,Or communicate the appropriate solution with the seller.
Application
Suitable for less than 750W all 36V DC equipment. E-bike, scooters, etc.
About shipping
The default product is sent within 72 hours and the customized product is sent within the delivery period.
Shipping reference time,
PostNL: 15-45 working days,DDU,Air transport
China Post: 20-60 working days,DDU,Train transportation
Seller's Shipping Method :The seller uses different logistics methods according to different regions. DDU or DDP. 15-60 working days. Air or Train.
UPS:7-25 working days, DDP,Air transport
FedEx:7-25 working days ,DDP,Air transport
Shipping list:
1 battery pack
Warning
Battery is a dangerous product. Before purchasing, please make sure that you understand the relevant knowledge of the lithium battery, and you can safely complete the installation of the battery pack or have a professional person assist in the installation. Improper operation may cause safety accidents, such as fire, explosion or equipment damage etc.. Please take all necessary precautions when using the battery.
Note:
*The default price does not include duty and tax,Except for special instructions.
* The weight of postal packages is limited to 2 kg. If you buy multiple products and the total weight exceeds 2 kg, it will be sent in multiple packages
* The weight and size data are obtained by manual measurement and may be subject to deviation.
* The performance parameter data comes from the CHUANGNDA laboratory. The actual test results will be affected by the test conditions (such as temperature, wire loss, test equipment accuracy, test parameters, etc.). Please perform multiple tests and take the average of the results to reduce the deviation.
The temperature is 25 degrees Celsius, and the deviation between the pure resistance discharge test results within the performance parameters and the description data is within 10%.
Company Profile
Dongguan Chuangnengda New Energy is a high-tech manufacturer specializing in the design, development, production, sales and service of lithium batteries (18650) for many years. In Dongguan and Shenzhen, factories have been established, and the company has a large number of high-quality professional and technical personnel and resources. Since its establishment, we have always adhered to a comprehensive quality management policy to provide customers with efficient, fast and convenient services. Production is strictly in accordance with the international IEC standards. During the entire production process, we strictly follow the three-level testing and development to ensure that the products meet the international standards. Products are widely used in electric tools, electric toys, emergency lights, flashlights, lawn lights, medical equipment, instrumentation, resource exploration, household appliances, film and television shooting, high-power lighting, mobile power supplies and other fields. Model airplanes, and various portable electrical equipment. Especially in the private customization of power tools and power battery pack solutions, it has strong advantages and characteristics. It has been in a leading position in the industry. The integrity, strength and product quality of Shenzhen Chuangnengda New Energy Co., Ltd. have been recognized by the industry. Friends from all walks of life are welcome to visit, guide and negotiate business.
