Installation and use (universal)
1. When the load changes during work, a cylinder with sufficient output power should be selected;
2. Under high temperature or corrosive conditions, the corresponding high temperature resistant or corrosion resistant cylinders should be selected;
3. When there is high humidity, excessive powder, or water droplets, oil, or welding slag, the cylinder should take corresponding protective measures
4. Before the cylinder is connected to the pipeline, the dirt in the pipeline must be removed to prevent the debris from entering the cylinder;
5. The medium used in the cylinder should pass through the filter element of 40μm or more before it can be used;
6. Because the front cover of the cylinder and the piston are short, the general stroke cannot be selected too large;
7. In a low temperature environment, anti-freezing measures should be taken to prevent the water in the system from freezing;
8. The cylinder should avoid side load as much as possible during the working process to maintain the normal operation and service life of the cylinder;
9. When the cylinder is removed and not used for a long time, pay attention to rust prevention on the surface, and add anti-clogging caps to the intake and exhaust ports. Pay special attention to:
The front and back covers cannot be disassembled by themselves.
