Профессиональный F118 F1118 6/16 In и Out аудио процессор блок питания последовательный

Vietnam India Indonesia Professional F118 F1118 6/16 In And Out Audio Processor Power Supply Sequence Controller

1. The total input reaches 40A.
2.30A high-power relay, each working output can reach 16A (2KW).
3. The opening delay interval of each channel is adjustable, which is suitable for the needs of special equipment on and off.
4.16A phosphor bronze universal socket.
5. High-quality new components, safety and stability.
6. Using high-response CPU, with RS232 control port, can be connected to centralized control equipment, with control instructions, stable and reliable communication.
7. Channel interlock can be set, suitable for electric screen.
8. The switch can be locked to prevent misoperation.
9. With RS232, it can be cascaded, (full control or individual control is also possible) up to 255 devices, only one RS232 port.
10. The channel individually controls the switch.
11. Digital display ID and channel delay peripherals.
12. Built-in lightning protection and anti-surge network.
13. With power-down memory function, you can customize the power-on state after power-off, or memorize the state of use before power-off.

1. Input power: 220V 50/60Hz
2. Output channels: 8 channels
3. Power input interface: live wire (Line), neutral wire (Neutral), earth wire (Earth) 3×6mm2 three-core coaxial cable
4. Power output interface: 8-way copper universal socket
5. Channel load output: the maximum output load of a single channel is 16A, and the maximum output load of the whole machine is 40A.
6. Switch device: Relay 30A/250VAC
7. Control input: 2×RS232 serial port
8. Use the control panel: 1 x toggle switch, used to set ID and delay settings
8×channel status LED indicator / 1 power status indicator
9. Use environment: temperature range -5℃ to 40℃
