Portable Flame and Plasma CNC Tube Cutting Machine

Portable Flame and Plasma CNC cutting machine is mainly used in all kinds of metal plates (such as: carbon

steel, stainless steel, aluminum, low alloy steel, aluminum alloy), but also in the complex pattern of the

above materials Processing.

Technical Specification
Product Name	CNC Portable Tube sheet dual-purpose cutting machine
Model	MS-1530X
Control System	SF-2100S
Motor	57 Stepper Motor
Color	Red,Blue,Yellow.
Cutting Mode	Plasma Cutting+ Flame Cutting
Flame Cutting Gas	Oxygen with propane or acetylene
Plasma Torch Gas	Compressed air/N2/O2
Working Area	1500mm*3000mm or 2000mm*3000mm
Cutting thickness	0-150mm
Cutting speed	0-8000mm/min
Operation precision	0.2mm/m



Main Features:

1. The whole machine structure is a portable cross-shaped structure, which is simpler to operate, lower in purchase cost, and more practical;
2. The whole machine operating system is the Shanghai Jiaotong University tube-sheet dual-use numerical control system (can be equipped with Beijing Starfun CNC system). This system supports tube-sheet dual-use; the cutting program can be cut directly by changing parameters in the system, greatly reducing labor cost.
3. It can realize the dual-purpose cutting method of flame plasma. The plasma can automatically adjust the arc voltage. The height adjuster adopts Hayes HP-105.
4.The cutting method is a tube-plate dual-purpose steel plate with a cutting range of 1500mm and a tube cutting diameter of 300mm
