Shanghai DM stone jaw crusher machine on sale equipment
Jaw Crusher
Brief Description:
Widely used in the Quarrying and Mining industries, the PEW Jaw Crusher series utilizes a marginally smaller eccentric throw than the PE series, however the PEW machines feature serrated side plates, and a slightly different designed crushing chamber to improve throughput capacities. The PEW units utilize a hydraulic adjusted double tapered wedge block system for variation of the CSS. This allows for a greater range of settings and less down time required to make conventional CSS adjustments.
Advantages and Characteristics:
The PEW Jaw Crusher series are versatile machines. Less weight and high production capacities makes these machines very well suited to Mobile Plants. They have a CSS range that allows the machine to be operated closed up tight to produce a higher percentage of fines, or wide open to produce high total throughput production.
Main Technical Parameters :
Model
| max feed size(mm)
| speed (rpm)
| power(kw)
| Capacity[TPH] Closed side setting [mm] | ||||||
| 100 | 125 | 150 | 200 | 225 | 250 | 300 | ||||
PEW-4230 | 1050×750 | 275 | 90-110 | 180 | 210 | 237 | 294 | 350 | ||
PEW-4836S | 1200×900 | 250 | 110-160 | 210 | 250 | 280 | 320 | 402 | ||
PEW-4840 | 1200×1000 | 250 | 132-160 |
| 265 | 302 | 370 | 480 | ||
PEW-6048 | 1500×1200 | 200 | 185-250 | 415 | 520 | 580 | 660 | 750 | ||
| Model | max feed size(mm) | speed (rpm) | power(kw) | Capacity(t/h) | Closed side setting (mm) | Weight(t) |
| PE-250×400 | 210 | 300 | 15 | 210 | 20-80 | 2.8 |
| PE-400×600 | 340 | 275 | 30 | 340 | 40-100 | 6.5 |
| PE-500×750 | 425 | 275 | 55 | 425 | 50-100 | 10.1 |
| PE-600×900 | 500 | 250 | 55 | 500 | 65-160 | 15.5 |
| PE-750×1060 | 630 | 250 | 110 | 630 | 80-140 | 28 |
| PE-800×1060 | 650 | 250 | 110 | 650 | 100-200 | 30 |
| PE-870×1060 | 670 | 250 | 110 | 670 | 200-260 | 30.5 |
| PE-900×1200 | 750 | 200 | 132 | 750 | 100-220 | 50 |
| PE-1000×1200 | 850 | 200 | 132 | 850 | 170-270 | 51 |
| PEX-250×750 | 210 | 330 | 22 | 210 | 25-60 | 4.9 |
| PEX-250×1000 | 210 | 330 | 30 | 210 | 25-60 | 6.5 |
| PEX-250×1200 | 210 | 330 | 37 | 210 | 25-60 | 7.7 |
| PEX-300×1300 | 250 | 330 | 55 | 250 | 25-60 | 11 |
Note:This specification is just reference,including Motor,any changes are subject to the Jaw Crusher products.
Crusher Line Case
Packaging & Shipping
Delivery for Stationary crushing plant
Our Services
1) Pre-sale service:
Freely provide project designing, process designing, choosing suitable equipment for you.
2) Medium-sales service:
Accompany you to complete the acceptance of the equipment,draft the construction scheme and
detailed process, and complete process of export.
3) After-sales service:
We sent engineer to the scene to guide installation, debugging and training operators.
4) Service supervision:
Any dissatisfaction on service attitude, service skills, quality and morality of our technical staff , please feel free to contact us by
dialing 24 hours hot line:0086-21-68911957.
Company Information
Shanghai DM Factory
Shanghai DongMeng Road&Bridge Machinery Co., Ltd. Is a leading professional manufacturer of crushing &screening
machinery in China. Shanghai Dongmeng set machinery design, development, production, sales, after-sales service as one.
We have more than 200 workers, 30 senior technical staff, with factory area of more than 20,000 square meters.
Certificate of Shanghai DM
Exhibition
FAQ
Q:Instalation ?
A:At the client’s request, DongMeng can provide installation Technicians to supervise and assist in the assembly and
commissioning of the equipment. Travel and accommodation costs.
Q:Payment?
A:30% by TT as deposit on signing the contract, 70% by as final payment of balance after the client’s satisfactory inspection of
the equipment prior to the goods leaving the DongMeng factory.
Q: What about Warranty? what will we do if the machine is broken down?
A: The warranty period for all of DongMeng’s structural and mechanical equipment is one year. The warranty period for all
electric motors is half one year. Wear parts are not covered by warranty unless the component part is found to be flawed.
Q: What should we need to do for if we want to get a best quotation?
A: Hi, if you want us recommend a suitable type for you ,please let us know as follows:
1).the capacity (tons per hour )?
A: Hi, if you want us recommend a suitable type for you ,please let us know as follows:
1).the capacity (tons per hour )?
2).output size?
3).Max.Input Size?
4).stone type?
Q: What could you help me to do for the business?
A: Many thanks for your trust , we can provide you with proposal chart for complete production lines ,
spot inspection and operator traning according to your demands and the conditions of applied spot , we can help you
choose the right equipments ,drilling rig ,loader ,trucks ,excavators and so on .
choose the right equipments ,drilling rig ,loader ,trucks ,excavators and so on .
Q:What's your After sales Service?
A:All equipment manufactured by DongMeng is of the highest standard and very rarely have our clients experienced any
mechanical problems. Should any problems occur, our team of Engineers and Technicians will respond within12 hours of
notice by the client.
Q:Delivery time?
A:Standard delivery time for stationary crusher plant is 30 days from receipt of deposit.the mobile crusher plant is 45 days.
