SNBC L520 портативный Wi-Fi принтер для промышленного производства

Item

BTP-L520

Print

Print method

Direct thermal

Resolution

203 DPI

Print width

Max.56mm

Print speed

Max.152mm/s

Memory

SDRAM:64MB, FLASH:4MB(standard) /8MB(optional)

Sensors

Top cover position, TPH overheating protection, Mark sensor, Paper existence

Drivers

Windows drivers(Win 2000/ XP /2003/ Win7/ Win 8) Linux, Mac

Button LED, LCD

1 button, 1 LED, 1 LCD (Optional)

Interface

Optional: Serial, Parallel, USB, Ethernet, WLAN(Wi-Fi)

Barcodes
Fonts
Graphics

1D Barcode

Code 3 of 9, UPCA, UPCE, Interleaved 2 of 5, code 128, EAN13, EAN8, HBIC (39 code with checkout), Codabar, industry CODE25, storage and transportation Code, UPC2, UPC5, Code 93, Postnet 25 (China), UCC/EAN, matrix 25, POSTNET code, etc.

2D Barcode

PDF417, MAXICODE, QR code etc.

Fonts

Normal used single-byte fonts:
FONT0~FONT8, 6 kinds of ASD smooth fonts, 8 kinds of Courier fonts; User-defined fonts: User can define font and download it to FLASH or SDRAM

Character modification

Rotate (0°,90°,180°,270°), enlarge (1-8x)

Graphics printing

Binary non-format bitmap, HEX, PCX, BMP and IMG bitmap can be downloaded to FLASH or RAM

Paper

Paper type

Continuous paper, Marked paper, Label paper

Paper width

Max.62mm

Paper out

Tear-off, peel-off

Paper roll ID

12.7mm/25.4mm

Paper roll OD

Max.127mm

Power supply

Input

100~240V AC,50~60Hz

Output

24V DC, 2.5A

Environment

Operation condition

5~45ºC,20~90%RH(40ºC)

Storage condition

-40~60ºC,20~93% RH(40ºC)

Physics Spec.

Dimensions

221(L)×125(W)×169(H)mm

Weight

Approx.1.1Kg

Standards

Standard

CCC, CE, FCC
