Ysonix M618 2 in 1 push type SIM connector 6pin SIM card +8pin TF card scoket combo Ysonix card reader for mobile phone
Product Description
1.General characteristics
Dimensions: 17.40L*16.50W*2.70H mm
Weight:Approx: 1.20±0.2g
Contact principle: Friction technology
Operating position: shaft up/down/horizontal
Mounting system: SMT(without post)
Durability: 5000 cycles min
2.Mechanical characteristics
Insulation material: Thermoplastic,UL 94V-0
3.Electrical characteristics
Number of contact: 8pin SIM+8Pin TF
Contact resistance: 50MΩ typical,100MΩ max
Insulation resistance: >1000 MΩ/500V DC
4.Solderability
Wave: not applicable
Vaporphase: 215oC,30sec Max
IR reflow: 260oC,10sec Max
Manual soldering: 360oC,3sec Max
5.Environmental characteristics
Operating temperature: -25oC − +70oC
Operating humidity: 10% − +95%RH
temperature: -40oC − +85oC
Storage humidity: 10% − +95%RH
Thermal shock: -40oC+85oC,5cycles
Damp Heat: 40oC,90%RH,500H
Salt-mist: 35oC,5%Nacl,48H
