The spiral freezer ia an engergy-saving fast freezing device with compact structer, wide application range , small occupied space and large freezing capacity. it is widely used fir quick freezubg if seafood , pastry , meat products,dairy products and prepared food. The freezer can be designed and manufancted accourding to customer's needs.Freezing capacity can be 200kg/h-3000kg/h.
Performance Characteristics
* The rapid freezing does not produce large ice crystals. The quality and freshness of the food remain maximized as original.
* The surface of the food quickly hardens and crusts, which can lock the internal moisture and minimize the drying loss of frozen products.
* The freezing time is extremely short and the energy consumption is low.
* Under the premise of same capacity, it has less space requirement than the traditional quick freezer
Product | Dumpling | Capacity | 800kg/h |
Product Configuration | - | Refrigerant | R22/R507A/R404A |
Freezing Method | IQF With/Without Package | Inner Air Humidity | -35℃ |
Inlet Temperature | +15℃ | Evaporating Temperature | -42℃ |
Outlet Temperature | -18℃ | Condensing Condition | Condensing Temp 40℃ Wet Bulb Temp 28℃ |
Item | Name | Spiral Freezer | ||
Model: | SF800 | |||
1. | Capacity: | 800kg/h | ||
2. | Library: | 6400 x 4600 x 3040mm | ||
3. | Belt With: | 550mm, 480mm effective | ||
4. | Qty of Tier: | 13 | ||
5. | Belt Length: | 152m,140m effective | ||
6. | Drum Diameter: | Φ2200mm | ||
7. | Tier Pitch: | 150mm (Passable Height 90mm) | ||
8. | Adjustable Range of Time: | 20 ~ 100 min | ||
9. | Length of Inlet & Outlet: | Inlet 1000mm Outlet 500mm | ||
10. | Height of Inlet & Outlet: | Inlet 800mm Outlet 2725mm | ||
11. | Defrosting Method and Period: | Water defrosting 1time/12h |
