Медицинский цифровой портативный Спирометр с фильтром
US $280.00-$460.00
Электронный цифровой спирометр легких/анализатор функции легких тестер
- Категории: Спирометр >>>
- Поставщик: Wuhan,Yidun,Medical,Instrument,Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
Electronic Digital lung Spirometer / Pulmonary Function Analyzer
Product Description
1.Meet the ITS, NIOSH, ERS and DIAGNOSIS standard.
2.Multi-language display and measurement report.
3.With precision flow sensor, easy to clean and sterilize, long-term durability.
4.5.7" 320*240 dots LCD, memory capacity 300 measurement records.
5.Built-in precise 110mm thermal printer.
6.Small size, light weight and easy to carry.
7.It can be connected to PC station through USB port, performing a pulmonary function test directly with PC station, also thousands of measurement records can be stored.
8.PC workstation supports the measurement and post-bronchodilator test.
9.PC workstation supports mulit-language display and report printing.
10.Support prediction equation for different races, includingITS, ECGS, KNUDSON, MORRIS/DOLGAR prediction equations
Feature of Portable Spirometer
1 | Meet the ITS, NIOSH, ERS and DIAGNOSIS standard |
2 | Multi-language display and measurement report |
3 | With precision flow sensor, easy to clean and sterilize, long-term durability |
4 | 5.7" 320*240 dots LCD, memory capacity 300 measurement records |
5 | Built-in precise 110mm thermal printer |
6 | Small size, light weight and easy to carry |
7 | It can be connected to PC station through USB port, performing a pulmonary function test directly |
8 | PC workstation supports the measurement and post-bronchodilator test |
9 | PC workstation supports mulit-language display and report printing |
10 | Support prediction equation for different races, includingITS, ECGS, KNUDSON, MORRIS/DOLGAR |
Specifications
| Display Screen | Diagonal line 5.7inches | Monochrome LCD | Resolution 320*240 |
| Control | Standard: UTILITY KEY, SVC KEY, FVC KEY, MVV KEY, PRINT KEY, 10WORDS KEY, [ ]KEY, KEY, START KEY, STOP KEY, KEY, KEY, KEY, KEY | ||
Measurement | Flow velocity detection: pressure gradient pneumatic flow sensor | ||
| Capacity detection: flow velocity integral | |||
| measuring range | Capacity range: 0L ~ 9L | Flow velocity range: 0 ~ 14L / s | |
measurement accuracy | Capacity: 0L ~ 1.6L (± 50ml) 6L ~ 9L (± 3%) | Flow rate: 5% or 0.2L / s | Respiratory rate: 4 / 20 ~ / min (± 1 / min) 20 / 60 / min (error: ± 5%) |
| measuring timelimit and degree | Vital capacity: every 50s, measuring 3 | FVC: per second, 25s, measuring 3 | The maximum ventilation volumn: every 12 seconds, measuring 3 |
| Power supply | AC: 100V~240V | DC: rechargeable Nickel-metal hydride (NI-MH), 14.4-volt, 1.8 amp hour | |
| Fuse | 100V~240V AC:F2A250V,5*20mm | ||
| Safety classification | IEC60601-1 class I, type CF | ||
Parameter
VC | Vital Capacity |
ERV | Expiratory Reserve Volume |
IRV | Inspiratory Reserve Volume |
TV | Tidal Volume |
IC | Inspiratory Capacity |
FVC | Forced Vital Capacity |
FEV0.5 | Forced Expiratory Volume in 0.5s |
FEV1.0 | Forced Expiratory Volume in 1s |
FEV3.0 | Forced Expiratory Volume in 3s |
FEV1.0%G | Forced Expiratory Volume in 1s/Forced Vital Capacity |
FEV1.0%T | Forced Expiratory Volume in 1s/Vital Capacity |
FEV3.0%G | Forced Expiratory Volume in 3s/Forced Vital Capacity |
FEV3.0%T | Forced Expiratory Volume in 3s/Vital Capacity |
Vext | Volume of Expiration |
Ex Time | Expiratory Time |
MMF | The maximum mid-expirator flow, same as MMEF |
PEF | Peak Expiratory Flow |
MEF75 | Maximum Expiratory Flow when 75% FVC remains, same as FEF25 |
MEF50 | Maximum Expiratory Flow when 50% FVC remains, same as FEF50 |
MEF25 | Maximum Expiratory Flow when 25% FVC remains, same as FEF75 |
FIVC | Forced Inspired Vital Capacity |
FIV0.5 | 0.5s Forced Inspired Volume |
FIV1.0 | 1s Forced Insipred Volume |
FIV1.0/FVC | Forced Inspired Volume in 1s/Forced Vital Capacity |
FIV1.0/FIVC | Forced Inspired Volume in 1s/Forced Inspired Vital Capacity |
PIF | Peak Inspiratory Flow |
MIF50% | Inspiratory Flow in 50% Inspired Capacity |
MVV | Maximum Voluntary Ventilation |
RR | Respiratory rate per minute |
TV | Tidal Volume in MVV measurement |
Certifications
Company Introduction
Why choose us?
1. One-Stop medical equipment purchase. Medical Shied have rich experience to help building up the new hospital and new clinic, supply thousands of medical items including Ultrasound scanner, ECG, ICU&Lab&Operation equipment, etc. To save your time, money, and energy.
2. TOP quality: We have strict quality control system, inspection before shipping, and enjoy good reputation in the market.
3. Competitive price: Factory based, lower prices than others. We shall offer discount for multiple items purchasing for our regular buyers.
4. Quick response Service Double-fast reply within 6 hours; 7days shipment service; Quick solution for item problem by professional engineer within 12hous.
Contact
PLEASE NOTE: Product images and descriptions may not exactly represent the product. Prior to making your purchase, before placing order, please CONTACT US FIRST and confirm that the specific item number shown above matches the product you seek.
Contact: Adam Hu
Wechat/whatsapp: +86 18007134205
Mobile: +86 18007134205
E: yidunmedical (at) outlook (dot) com
