Products Description
Foxtech AYK-250 is a long-endurance tail-pushed VTOL with high efficiency specifically designed for long-range inspection, surveillance and mapping jobs, which can realize 3.5H endurance with 1.2kg payload.
- Carbon fiber integrated molding process, light and durable.
- Aerodynamic design and smooth surface ensure a low air resistance.
- Quick-detach design, easy to assembly.
- Detachable tail design and payload compartment.
Specification | ||
Wingspan | 2500mm | |
Frame Weight | 3.2kg | |
Max. Take-off Weight | 13.5kg | |
Max. Payload | 2.2kg | |
Endurance | 3.5H@12.5kg | |
Max. Cruising Speed | 93.6km/h(26m/s) | |
Battery | 2x25000mAh Lipo | |
Stall Speed | 15.5m/s@12.5kg | |
Wind Resistance | 10.8m/s-13.8m/s(fixedwing); 5.5m/s-7.9m/s(vtol) | |
Details Images
Your Purchase Includes:
Pixhawk RTF:
1x AYK-250 VTOL Frame
4x VTOL Motor KV260
4x VTOL ESC 60A
1x Motor KV230 for Fixedwing Mode
1x ESC 115A HV for Fixedwing Mode
2x Pair 17inch Propeller
1x 1712 CW Wooden Propeller
4x Servo
1x Pixhawk Cube Orange Standard Set with Here 3 GNSS
1x DA16S+ Radio Controller
1x 25A BEC
1x Air Speedometer
1x Carrying Case
1x Assembling,tuned and Flying Test Service
CUAV X7 RTF:
1x AYK-250 VTOL Frame
4x VTOL Motor KV260
4x VTOL ESC 60A
1x Motor KV230 for Fixedwing Mode
1x ESC 115A HV for Fixedwing Mode
2x Pair 17inch Propeller
1x 1712 CW Wooden Propeller
4x Servo
1x CUAV X7 Flight Controller with NEO V2 Pro GNSS
1x DA16S+ Radio Controller
1x 25A BEC
1x Air Speedometer
1x Carrying Case
1x Assembling,tuned and Flying Test Service
CUAV V5+ RTF:
1x AYK-250 VTOL Frame
4x VTOL Motor KV260
4x VTOL ESC 60A
1x Motor KV230 for Fixedwing Mode
1x ESC 115A HV for Fixedwing Mode
2x Pair 17inch Propeller
1x 1712 CW Wooden Propeller
4x Servo
1x CUAV V5+Flight Controller with NEO V2 Pro GNSS
1x DA16S+ Radio Controller
1x 25A BEC
1x Air Speedometer
1x Carrying Case
1x Assembling,tuned and Flying Test Service
1x AYK-250 VTOL Frame
4x VTOL Motor KV260
4x VTOL ESC 60A
1x Motor KV230 for Fixedwing Mode
1x ESC 115A HV for Fixedwing Mode
2x Pair 17inch Propeller
1x 1712 CW Wooden Propeller
4x Servo
1x Pixhawk Cube Orange Standard Set with Here 3 GNSS
1x DA16S+ Radio Controller
1x 25A BEC
1x Air Speedometer
1x Carrying Case
1x Assembling,tuned and Flying Test Service
CUAV X7 RTF:
1x AYK-250 VTOL Frame
4x VTOL Motor KV260
4x VTOL ESC 60A
1x Motor KV230 for Fixedwing Mode
1x ESC 115A HV for Fixedwing Mode
2x Pair 17inch Propeller
1x 1712 CW Wooden Propeller
4x Servo
1x CUAV X7 Flight Controller with NEO V2 Pro GNSS
1x DA16S+ Radio Controller
1x 25A BEC
1x Air Speedometer
1x Carrying Case
1x Assembling,tuned and Flying Test Service
CUAV V5+ RTF:
1x AYK-250 VTOL Frame
4x VTOL Motor KV260
4x VTOL ESC 60A
1x Motor KV230 for Fixedwing Mode
1x ESC 115A HV for Fixedwing Mode
2x Pair 17inch Propeller
1x 1712 CW Wooden Propeller
4x Servo
1x CUAV V5+Flight Controller with NEO V2 Pro GNSS
1x DA16S+ Radio Controller
1x 25A BEC
1x Air Speedometer
1x Carrying Case
1x Assembling,tuned and Flying Test Service
