SNBC BTP-U106t 104 мм a6 4 дюйма для того чтобы свернуть ленты стикер Принтер тепловой принтер штрих-кодов

Item

BTP-U106t

Print

Print method

Thermal/Thermal transfer

Resolution

203 DPI

Print width

Max.104mm

Print speed

Max.150mm/s

Memory

SDRAM:16MB, FLASH:4MB

Button, LED

1button, 2 LED

Interface

Standard:USB , Optional:Serial

Operation interface

Button, LED

1 Button, 2 LEDS

Detection

Sensors

Transmission sensor (movable) , Reflection sensor (movable)

Programming language

Command set

BPLT, BPLZ,BPLE

Barcodes Fonts Graphics

Barcodes

1D: Code 39, UPCA, UPCE, Interleaved 2 of 5, code 128, EAN 13, EAN8, HBIC (39 code with checkout), Codabar, industry Interleaved 2 of 5, CODE 93, LOGMARS, GS1 Databar etc. 2D: GS1 Databar PDF417, MAXICODE, QR code Datamatrix, GS1 Composite

Paper

Paper type

Continuous paper, Marked paper, Label paper

Paper roll width

19-120mm

Paper roll OD

Max.127mm

Ribbon

Ribbon length

Max.300M

Ribbon roll ID

12.7/25.4mm

Power supply

Input

100~240V AC,50~60Hz

Output

24V DC, 2.5A

Environment

Operation condition

5~45ºC,20~90%RH(40ºC)

Storage condition

-40~60ºC,20~93% RH(40ºC)

Physics Spec.

Dimensions

278(W)×218(D)×185(H)mm

Weight

Approx.2.3Kg
