Product Overview
Automatic heavy duty Gear cnc Shaping Hobbing Machine
CNC gear shaping machine is widely used in processing all kinds of disc teeth, shaft teeth and helical teeth (need to add helical
tooth accessories) and other parts, especially suitable for engineering machinery, mining machinery, automobile, wind power,
aviation and other industries of mass production, but also suitable for single or small batch processing.
This machine tool is a vertical gear shaper with longitudinal layout, which is mainly composed of bed, middle bed, worktable,
column, tool rest, drive box and other main components. This machine tool is three-axis CNC machine tool, which can realize
three-axis linkage, ac servo drive, CNC control.
tooth accessories) and other parts, especially suitable for engineering machinery, mining machinery, automobile, wind power,
aviation and other industries of mass production, but also suitable for single or small batch processing.
This machine tool is a vertical gear shaper with longitudinal layout, which is mainly composed of bed, middle bed, worktable,
column, tool rest, drive box and other main components. This machine tool is three-axis CNC machine tool, which can realize
three-axis linkage, ac servo drive, CNC control.
FEATURES AT A GLANCE
1. Main movement: the cutting tool moves up and down, and the main motor is controlled by ac inverter to realize stepless speed
regulation;
2. Peripheral tooth movement of cutter: C2 axis, driven by ac servo motor;
3. Peripheral tooth movement of the workbench: C1 axis, driven by ac servo motor worm gear pair of the workbench;
4. Vertical column radial feed motion: X axis, driven by ac servo motor ball screw driven vertical column to realize the radial
feed motion of the machine tool;
5, the empty stroke of the tool to let the movement of the knife: through the CAM, roller drive the swing of the knife, to achieve
the radial tooth inside and outside of the knife;
6. The cutter stops moving.
In addition, the stroke length of the cutter shaft is adjusted by adjusting the position of the stroke shaft on the crank disk;
Adjust the machining position (cutter position) of the cutter by rotating the ball pull rod; According to the actual processing
conditions to set the feed speed, cycle number and cutting depth (in the coarse, fine machining to achieve automatic
transmission);The machine tool is provided with an inclined cutting mechanism.
regulation;
2. Peripheral tooth movement of cutter: C2 axis, driven by ac servo motor;
3. Peripheral tooth movement of the workbench: C1 axis, driven by ac servo motor worm gear pair of the workbench;
4. Vertical column radial feed motion: X axis, driven by ac servo motor ball screw driven vertical column to realize the radial
feed motion of the machine tool;
5, the empty stroke of the tool to let the movement of the knife: through the CAM, roller drive the swing of the knife, to achieve
the radial tooth inside and outside of the knife;
6. The cutter stops moving.
In addition, the stroke length of the cutter shaft is adjusted by adjusting the position of the stroke shaft on the crank disk;
Adjust the machining position (cutter position) of the cutter by rotating the ball pull rod; According to the actual processing
conditions to set the feed speed, cycle number and cutting depth (in the coarse, fine machining to achieve automatic
transmission);The machine tool is provided with an inclined cutting mechanism.
maximum machining diameter | 2200 mm（No small pillar） 1000 mm（ small pillar） |
Maximum number of processing mode | 16mm |
Maximum processing width | 500mm |
Minimum number of teeth of workpiece | 12 |
Maximum bearing weight | 3T |
Head vertical range | 800MM |
Swing angle of tool post | ±60° |
Distance from hob axis to table surface | max1000 mm min200 mm |
Taper hole for hob spindle | Morse cone No. 6 |
Maximum size of hob | length220 mm |
Maximum axial Series distance of hob (manual) | 100MM |
Diameter of hob mandrel | φ27、φ32、φ40、φ50 |
Tool speed/series | 16、22.4、31.5、45、63、90、125r/min 7level |
Distance from hob axis to worktable center of rotation | min100 mm max1250 mm |
Maximum table speed | 5r/min |
Worktable diameter | 950 mm |
Table hole diameter | 200MM |
Taper of workpiece mandrel seat hole | Morse cone No. 6 |
Knife rest slide plate moves fast | 520mm/min |
Rapid feed speed of table | 470mm/min |
Axial feed series and feed range | 8level 0.39～4.39 mm/r |
Distancefromworktabletolowerendofrearcolumnsupportsleeve | min700 mm max1200 mm |
Main motor power and speed | 11kw、1460r/min |
Axial fast motor power and speed | 3kw、1420r/min |
Table for fast motor power and rotation | 1.5kw、940r/min |
Hydraulic pump motor power and speed | 1.5kw、940r/min |
Cooling pump motor power and speed | 1.5kw、1460r/min |
Total power of machine | 18.5KW |
net weight | 15000KG |
size | 3995×2040×2700mm |
