Products Description
WB Plate feeder, designed and produced by FTL Machinery, is generally divided into three types: heavy, medium and light, which is commonly used in concentrator.
Light plate feeder is a continuous feeding machine, which is suitable for short distance conveying of bulk materials with particle size less than 160mm. In mines, concentrators, chemical industry, cement, building materials and other departments, it is widely used for uniform and continuous feeding from storage bin to crushing, transportation and other machinery. It can be installed horizontally or obliquely with a large upward inclination of 20 degrees. It is generally suitable for materials with loose density less than 1200kg / m3, block weight less than 140kg and temperature below 350 ℃.
Application Industry: mine, concentrator, chemical industry, cement, building materials
Applicable material: block material
Processing capacity: 10-900t / h
Light plate feeder is a continuous feeding machine, which is suitable for short distance conveying of bulk materials with particle size less than 160mm. In mines, concentrators, chemical industry, cement, building materials and other departments, it is widely used for uniform and continuous feeding from storage bin to crushing, transportation and other machinery. It can be installed horizontally or obliquely with a large upward inclination of 20 degrees. It is generally suitable for materials with loose density less than 1200kg / m3, block weight less than 140kg and temperature below 350 ℃.
Application Industry: mine, concentrator, chemical industry, cement, building materials
Applicable material: block material
Processing capacity: 10-900t / h
Details Images
Process introduction
WB Plate feeder is generally divided into three types: heavy, medium and light, which is commonly used in concentrator.
Light plate feeder is a continuous feeding machine, which is suitable for short distance conveying of bulk materials with particle size less than 160mm. In mines, concentrators, chemical industry, cement, building materials and other departments, it is widely used for uniform and continuous feeding from storage bin to crushing, transportation and other machinery. It can be installed horizontally or obliquely, with a large upward inclination of 20 degrees. It is generally suitable for materials with loose density less than 1200kg / m3, block weight less than 140kg and temperature below 350 ℃.
Light plate feeder is a continuous feeding machine, which is suitable for short distance conveying of bulk materials with particle size less than 160mm. In mines, concentrators, chemical industry, cement, building materials and other departments, it is widely used for uniform and continuous feeding from storage bin to crushing, transportation and other machinery. It can be installed horizontally or obliquely, with a large upward inclination of 20 degrees. It is generally suitable for materials with loose density less than 1200kg / m3, block weight less than 140kg and temperature below 350 ℃.
Our Advantages
WB Medium sized plate feeder is intermittent feeding machine, which is suitable for short distance conveying of bulk materials with particle size less than 400mm. In mines, concentrators, chemical industry, cement, building materials and other departments, it is widely used for uniform intermittent feeding from storage bin to crushing, transportation and other machinery. It can be installed horizontally or obliquely, with a large upward inclination of 20 degrees. It is generally suitable for materials with loose density less than 12400kg / m3, block weight less than 500kg and temperature below 400 ℃.
WB Heavy plate feeder is the auxiliary equipment of transport machinery. It is used in crushing and grading workshop of large concentrator, cement, building materials and other departments. It is used for continuous and uniform feeding from silo to primary crusher. It can also be used for short distance transportation of materials with large particle size and specific gravity. It can be installed horizontally or obliquely with a large inclination of 12 degrees. In order to avoid the material hitting the feeder directly, the silo should not be empty.
WB Heavy plate feeder is the auxiliary equipment of transport machinery. It is used in crushing and grading workshop of large concentrator, cement, building materials and other departments. It is used for continuous and uniform feeding from silo to primary crusher. It can also be used for short distance transportation of materials with large particle size and specific gravity. It can be installed horizontally or obliquely with a large inclination of 12 degrees. In order to avoid the material hitting the feeder directly, the silo should not be empty.
WB Various types of plate feeder are divided into right and left transmission according to the transmission mode. The transmission system on the right side of the machine is right transmission along the material running direction, and on the contrary, it is left type transmission.
Product Paramenters
Type | Width of groove plate (mm) | Center distance of head and tail axle (mm) | Feeding speed (M/s) | Maximum feed size (mm)) | Feed rate T / h | dip angle. | Motor power kw |
WB1000*8 | 1000 | 8000 | 0.02-0.054 | 600 | 40-100 | 0-23 | 11 |
WB1250*9 | 1250 | 9000 | 0.013-0.06 | 700 | 40*180 | 0-23 | 15 |
WB1500*9 | 1500 | 9000 | 0.03 | 800 | 200 | 0-23 | 15 |
WB1600*9 | 1600 | 9000 | 0.076 | 800 | 180 | 0-23 | 22 |
WB1750*9 | 1750 | 9000 | 0.03-0.1 | 800 | 200-675 | 0-25 | 37 |
WB1800*10 | 1800 | 1000 | 0.022-0.066 | 1200 | 200-650 | 0-23 | 45 |
