Патроны 72 дюйма приспособление для захвата метлы и вспомогательные
- Категории: Loaders >>>
- Поставщик: Boleo,Machinery,Equipment,(changzhou),Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
Product Description
FEATURES
● Mounts to skid steer quick attach
● Direct drive Eaton® motor, high strength bucket and intelligent design ensure many years of performance,with relief valve protection, ensuring long hydraulic life
● 15-24 GPM flow, All Polypropylene bristles
● Heavy-duty bucket design
● Bi-directional broom sweeps forward to pick up dirt, rock and construction debris
● To dump, lift and tilt, no chains required
● No front caster wheel, works next to walls, curbs and obstacles
● Replaceable bolt-on cutting edge on bucket
● Direct-drive brush motor eliminates chains and sprockets
● Available colors
● Direct drive Eaton® motor, high strength bucket and intelligent design ensure many years of performance,with relief valve protection, ensuring long hydraulic life
● 15-24 GPM flow, All Polypropylene bristles
● Heavy-duty bucket design
● Bi-directional broom sweeps forward to pick up dirt, rock and construction debris
● To dump, lift and tilt, no chains required
● No front caster wheel, works next to walls, curbs and obstacles
● Replaceable bolt-on cutting edge on bucket
● Direct-drive brush motor eliminates chains and sprockets
● Available colors
SPECIFICATIONS | ||||||
Model | BPB60 | BPB72 | BPB84 | |||
Overall Length(mm) | 1450 | 1450 | 1450 | |||
Overall Width(mm) | 1817 | 2117 | 2466 | |||
Overall Height(mm) | 926 | 926 | 926 | |||
Height(support spring is not included)(mm) | 680 | 680 | 680 | |||
Weight(Kg) | 456 | 480 | 540 | |||
Capacity of Collection Hopper(m3) | 0.39 | 0.46 | 0.56 | |||
Actual Sweep Width(mm) | 1530 | 1830 | 2130 | |||
Diameter of Brushes Roller(mm) | 660 | 660 | 660 | |||
Max.working Pressure(Mpa) | 21 | 21 | 21 | |||
Required Hydraulic Flow(L/min) | 60-80 | 60-80 | 80-90 | |||
Suitable machine | Skid Steer Loader/Loader/Backhoe | |||||
Compatible Carrier | Atomizaton dust elimination system | |||||
Cleaning system of side brushes | ||||||
