EBKN EN-3802 устройство для считывания отпечатков пальцев в школе 1000 пользователей времени биометрическая

Item

Function

Description

Hardware function

CPU

BR8220

Fingerprint scanner

Optical fingerprint head(DEG931 20pin)

ID card

Supported

Display

2.4”,2.8” TFT LCD

Keyboard

16 physical keys

Communication method

cable network, P2P

USB HOST

Supported

Clock RTC

Supported

Voice output

Supported

Wiegand input port

Supported

Wiegand output port

Supported

Open door button

Supported

Door magnetic switch

Supported

Door opening relay

Supported

Ring relay

Supported

Anti-demolish button

Supported

Administrator delete button

Supported

Backup battery interface

Supported

Size

Same as the main board size and the external interface location of S260T

Operating voltage

DC 9~12V

Operating temperature

-10℃~ +60℃

Operating humidity(RH)

20% ~ 80%

Software function

Log capacity

1,000

Attendance Log capacity/Mgt. Log capacity

100,000/10,000

Identify mode

Fingerprint,card,pin and combinations

Language

Chinese,English and so on in S260T

Fingerprint algorithm

Algorithm version

EBKNFinger V3.0

FAR/ FRR

0.00001/ 0.1(%)

Matching speed

Less than 0.8s (when 1000 fingerprint logged)

Contrast angle

360 degree free rotation

Intelligent update function

Supported

Fingerprint recognition mode

1:1, 1:N
