71936C Высокоточный радиально-упорный шарикоподшипник 180*250*33


Поделиться:

Цена:*
Стоимость в USD (на сегодня):Узнать

Количество:

Описание и отзывы

Характеристики



Product Description


71936C Super precision angular contact ball bearing




Detail image




Specification


item
value
Type
BALL
Structure
Angular Contact
Applicable Industries
Building Material Shops, Manufacturing Plant, Machinery Repair Shops
Brand Name
SDVV
Precision Rating
P4
Seals Type
OPEN
Number of Row
Single Row
Place of Origin
Germany
Product name
71936C
Size
180*250*33mm
Inside diameter
180mm
Outside diameter
250mm
Width
33mm
Basic dynamic load rating
152 kN
Basic static load rating
184 kN
Attainable speed for grease lubrication
4900 r/min
Attainable speed for oil-air lubrication
7700 r/min
Contact angle
15°
Mass bearing
4.76kg


Similar model bearings


Bearing No.
d(mm)
D(mm)
B(mm)
71800C
10
19
5
71801C
12
21
5
71802C
15
24
5
71803C
17
25
5
71804C
20
32
7
71805C
25
37
7
71806C
30
42
7
71807C
35
47
7
71808C
40
52
7
71809C
45
58
7
71810C
50
65
7
71811C
55
72
9
71812C
60
78
10
71813C
65
85
10
71814C
70
90
10
71815C
75
95
10
71816C
80
100
10
71817C
85
110
13
71818C
90
115
13
71819C
95
120
13
71820C
100
125
13
71821C
105
130
13
71822C
110
140
16
71824C
120
150
16
71826C
130
165
18
71828C
140
175
18
71830C
150
190
20
71832C
160
200
20
71834C
170
215
22
71836C
180
225
22
71838C
190
240
24
71840C
200
250
24
71844C
220
270
24
71848C
240
300
28
71852C
260
320
28
71856C
280
350
33
71860C
300
380
38
71864C
320
400
38
71868C
340
420
38
71872C
360
440
38
71876C
380
480
46
71880C
400
500
46
71884C
420
520
46
71888C
440
540
46
71892C
460
580
56
71896C
480
600
56
718/500C
500
620
56






Company Profile




Jinan Deyi Ruisheng Mechanical and Electrical Equipment Co., Ltd. is a subsidiary of Hong Kong SUN RISES GROUP LTD. It is a group company whose main business is bearing export. The company's products sell well in Southeast Asia, South America, Africa, the Middle East, North America, Europe, etc. many countries.Sun Rises Group Limited. was established in 1986, is a professional exporter of bearings and other industrial products. Our own brand is SDVV and we also agent for many world-famous bearings, the bearing brands include: SKF bearings, FAG bearings, INA bearings, TIMKEN bearings, KBC bearings and a series of Japanese bearings (NSK, NTN, KOYO, IKO, NACHI, ASAHI, FYH, NMB, THK bearings and so on).

Bearing Types: deep groove ball bearings, self-aligning ball bearings, angular contact ball bearings, thrust ball bearings, cylindrical roller bearing, tapered roller bearings, spherical roller bearings, CARB toroidal roller bearings, needle roller bearings, cylindrical roller thrust bearings, tapered roller thrust bearings, spherical roller thrust bearings, needle roller thrust bearings, supper precision bearings, INSOCOAT bearings, high-temperature bearings, stainless steel bearings, cam rollers, support rollers, cam followers, track rollers, plain bearings, Y-bearings (insert bearings), cross roller bearings, rolling mill bearings, bearings housings and units, plummer block housings, slewing bearings,split bearings, thin section bearings, joint bearings, bearing accessories (adapter sleeves, withdrawal sleeves and lock nuts) etc. We can also supply some uncommon bearings such as non-standard bearings, linear bearings, automobile bearings, Mega-bearings, railway bearings, etc. as well as Bearing Tools such as SKF Bearing Heaters, SKF Precision Metric Shim Kits TMAS, etc.














1. who are we?
We are based in Shandong, China, start from 2015,sell to South America(18.00%),Eastern Europe(15.00%),Africa(15.00%),Mid
East(10.00%),Western Europe(10.00%),North America(8.00%),Northern Europe(6.00%),Southern Europe(5.00%),Southeast
Asia(5.00%),Eastern Asia(5.00%),South Asia(1.00%),Central America(1.00%),Oceania(1.00%). There are total about 51-100 people in
our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
SKF bearings,TIMKEN bearings,NSK bearings,FAG bearings,INA bearings

4. why should you buy from us not from other suppliers?
In accordance with ISO standards, we have professional Q/C staff, precision testing instruments and internal inspection system,
the quality control is implemented in every process from material receiving to products packaging to ensure our bearings quality

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FCA,Express Delivery;
Accepted Payment Currency:USD,EUR,HKD,CNY;
Accepted Payment Type: T/T,L/C,MoneyGram,PayPal,Western Union;
Language Spoken:English,Chinese


We have sufficient inventory to achieve fast delivery. If you want to know more, please feel free to contact us so that we can get back to you quickly.
