Лидер продаж дорожная техника мини-автогрейдер Sem917 с
- Категории: Motor Graders >>>
- Поставщик: Anhui,Heavy,And,Light,Industries,International,Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
Products Description
Product Description
Advantages
* High Performance: Load sensing variable piston pump and specially designed PPPC valves provide superior implement control and
better machine performance.* High Reliability: Specially designed SEM tandem axle, flanged large box section front frame, A-shape
drawbar frame with box section, are designed to handle heavy duty applications providing excellent reliability and durability.
Advantages
* High Performance: Load sensing variable piston pump and specially designed PPPC valves provide superior implement control and
better machine performance.* High Reliability: Specially designed SEM tandem axle, flanged large box section front frame, A-shape
drawbar frame with box section, are designed to handle heavy duty applications providing excellent reliability and durability.
Model | SEM917 | |
Item | Unit | Parameters |
Operating Weight | ||
Standard | kg | 13,500 / 13,820 (EAEU) |
With Ripper+Front Counterweight | kg | 13,780 / 14,100 (EAEU) |
With Front Blade | kg | 14,130 / 14,450 (EAEU) |
With Ripper+Front Blade | kg | 14,410 / 14,730 (EAEU) |
Operating Specifications | ||
Top Speed, Forward | km/h | 40 |
Top Speed, Reverse | km/h | 29 |
Min. Turning Radius | mm | 7300 |
Articulation Angle, Left / Right | ° | 20 |
Gradeability | ° | 30 |
Wheelbase | mm | 5830 |
Travel Speed, Forward | km/h | 5.3 / 8.2 / 13.3 / 20.3 / 29 / 40 |
Travel Speed, Reverse | km/h | 5.3 / 13.3 / 29 |
Drawbar Pull | kN | 78 |
Engine | ||
Engine Manufacturer | SDEC (ShangHai Diesel) | |
Engine Model | SC7H170. 1G2B | |
Rated Power | kW @ RPM | 125 @ 2,200 |
Max. Torque | kN @ RPM | 750 @ 1,400 |
Emission | Tier 2 | |
Displacement | L | 6.5 |
Bore | mm | 105 |
Strokemm124 | mm | 124 |
Number of Cylinders | 6 | |
Blade Width, Standard | mm (inch) | 3,669 (12') |
Blade Width, Optional | mm (inch) | 3,972 (13') |
