Product Description


 China Top 1 Brand 100HP Motor Grader Gr1003 for Sale


GR1003 road grader is mainly used for ground leveling, ditching, slope scraping,bulldozing, scarification, snow removal for large areas such as highway, airports, farmlands etc.





road grader GR1003 is the necessary construction machinery for national defense construction,mine construction, urban and rural road construction and water conservancy construction, farmland improvement and so on.





Performance Characteristics:





1. Efficient operation: the optimized blade shape can turn and remove the soil quickly and efficiently, and realize optimal load distribution and the minimum material accumulation within the rotary discarea.





2. Safe and reliable: full hydraulic braking system, load sensing steering system, international supporting key components, ensuring safe and reliable system.





3. Advanced processing technology: all important parts and components are welded by international advanced welding equipment, which is characterized by high weld strength, uniform welding line and high welding quality.





4. Maintenance accessibility:  road grader GR1003 adopting the backflip hydraulic lift hood, the machine cover is has large opening, easy for maintenance and repair of the machine.





Specification


 China Top 1 Brand 100HP Motor Grader Gr1003 for Sale
























































































































Item





Unit


GR1003


Basic parameters


Engine model





WP4.1


Rated power/speed


kW/rpm


75/2200


Overall dimension(standard)


mm


7130 x 2375 x 3150


Total weight(standard)


kg


7500


Tire specification





16/70-24/13.00-24


Ground clearance


mm


550


Tread


mm


1900


Space of front and rear axles


mm


5135


Space of middle and rear wheels


mm


/


Performance parameters


Forward velocity


km/h


5,8,11,17,24,38


Reverse speed


km/h


5,11,24


Tractive effort f=0.75


kN


≥39


Maximum gradeadbility


%


≥25


Inflation pressure of tires


kPa


300


Working system pressure


MPa


16


Transmission pressure


MPa


1.3-1.8


Working parameters


Maximum steering angle of front wheels


°


±49


Maximum inclination angle of front wheels


°


±17


Maximum swing angle of front axle


°


±15


Maximum swing angle of balance box


°


±16


Maximum steering angle of frame


°


±27







 China Top 1 Brand 100HP Motor Grader Gr1003 for Saleno logo motor grader (73).JPGno logo motor grader (74).JPGno logo motor grader (75).jpgno logo motor grader (76).jpgno logo motor grader (77).jpg
