Products Description
Stainless Steel Air Shower
Feature
1.Air shower is when operators enter the clean room using personal purification device.
2.It uses a high-speed clean air shower to remove body dirt and adjust the nozzle into the room personnel effectively remove dust out of the man.
3.Air shower room also plays a role in Airlock to prevent entering clean areas without clean air, and to prevent external contamination into clean areas.
4.Subjects are made of cold-rolled sheet spray plastic or stainless steel plate processing, and centrifugal fan configuration and initial efficiency and high efficiency air filters, with appearance of compact structure, easy maintenance, simple operation and so on.
5.By photoelectric sensing two door interlock switch, automatically opening and closing, and people (goods) in and out of convenience.
6.Air shower room control system adopts PLC control system.
Feature
1.Air shower is when operators enter the clean room using personal purification device.
2.It uses a high-speed clean air shower to remove body dirt and adjust the nozzle into the room personnel effectively remove dust out of the man.
3.Air shower room also plays a role in Airlock to prevent entering clean areas without clean air, and to prevent external contamination into clean areas.
4.Subjects are made of cold-rolled sheet spray plastic or stainless steel plate processing, and centrifugal fan configuration and initial efficiency and high efficiency air filters, with appearance of compact structure, easy maintenance, simple operation and so on.
5.By photoelectric sensing two door interlock switch, automatically opening and closing, and people (goods) in and out of convenience.
6.Air shower room control system adopts PLC control system.
Model | Single Single Blow Air Shower | Single Double Blow | Double Double Blow | ||
Outside Dimension (mm) | 1290×1000×2050 | 1590×1000×2050 | 1590×2000×2050 | ||
Air Shower Area (mm) | 790×910×1930 | 790×910×1930 | 790×1910×1930 | ||
Air Velocity at the Nozzle | 15~20M/S | ||||
Number Of Nozzles | 6 Pieces(Single) | 12Pieces(Double) | 24Pieces(Double) | ||
Air Shower Time | 0~99s(Adjustable) | ||||
filter efficiency | ≥99.99% | ||||
Meterial | 1.2mm thickness cold-rolled plate,surface static href="##" electricity href="##" spurts href="##" models href="##" processing or 1.2mm stainless steel plate. | ||||
The material and number of door | Stainless steel single door*2 pieces | ||||
The door of interlocked manner | Air shower double door lock, usually two-door electronic interlocking, can open a door. | ||||
Power Supply | 380V | ||||
Capacity | 1.2KW | 2.3KW | 4.6KW | ||
Weight | ~360KG | ~420KG | ~840KG | ||
Number of Users | 1~2 people | 1~2 people | 2~4 people | ||
Advantages and Functions
1) Material: Stainless Steel SUS304;
2) Electronic Interlock. When A door opens, B door is locking. A, B doors can not open when blowing;
3) Emergency off button is installed according to customers' needs in case of emergency happens. Once press, two doors open;
4) Color LCD screen, touch-point switch to control blowing time and lamp time. It shows reminder of HEPA filter replacement when needed;
5) Infrared sensor automatic blowing, automatic stop;
6) Two-side blowing, left and right, stainless steel nozzles. Three-side blowing can be provided according to customers' needs;
7) Germany Dorma door closer, stable. China KFC stores also choose this type as their door closer;
8) 360-degree rotatable nozzles are installed according to customers' needs to keep high efficiency for blowing off particles from personnel;
9) Have electronic interlock air shower patent.
1) Material: Stainless Steel SUS304;
2) Electronic Interlock. When A door opens, B door is locking. A, B doors can not open when blowing;
3) Emergency off button is installed according to customers' needs in case of emergency happens. Once press, two doors open;
4) Color LCD screen, touch-point switch to control blowing time and lamp time. It shows reminder of HEPA filter replacement when needed;
5) Infrared sensor automatic blowing, automatic stop;
6) Two-side blowing, left and right, stainless steel nozzles. Three-side blowing can be provided according to customers' needs;
7) Germany Dorma door closer, stable. China KFC stores also choose this type as their door closer;
8) 360-degree rotatable nozzles are installed according to customers' needs to keep high efficiency for blowing off particles from personnel;
9) Have electronic interlock air shower patent.
Our Advantages
Certifications
Packing&Shipping
FAQ
