1200 Вт 60 в 20 А супер мощный Интеллектуальный лабораторный источник питания для защиты от перегрузки тока ремонта мобильного
- Категории: Power Supplies >>>
- Поставщик: Shenzhen,Mestek,Electronics,Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
Product Description
Product Paramenters
Model | DP6020 | ||||||
The output voltage | 0-60V | ||||||
Output current | 0-20A | ||||||
The output voltage | Constant voltage value range: 0-V rated value, continuously adjustable | ||||||
Output current | Constant current value range: 0-A rated value, continuously adjustable | ||||||
Way of working | Automatic switching of voltage and steady current state | ||||||
Constant pressure indication | CV, green LED indicator | ||||||
Constant current indication | CC, red LED indicator | ||||||
Display resolution | Three-digit display: voltage 0.1V, current 0.1A Automatic mA display: 0-999mÁ (specification within 5A of output current) | ||||||
Display accuracy | ±1% ± 1word | ||||||
Power effect | CV ≤0.05%+ 1mV CC ≤0.05%+ 1mA | ||||||
Load effect | CV ≤0.1%+ 5mV CC ≤0.1%+ 10mA | ||||||
Ripple noise | CV ≤10mV RMS CC ≤20mA RMS | ||||||
Protective function | Over voltage, over temperature, short circuit current limit protection | ||||||
Cooling method | -10- 40 celsius relative temperature<80% | ||||||
Working environment | -10-40 celsius relative humidity<80% | ||||||
Storage temperature | -20-80 celsius relative humidity<80% | ||||||
Physical dimension | 260*125*160mm/(L ength*width*height)mm | ||||||
Weight | 5Kg | ||||||
Company Profile
Shenzhen Mestek Electronics Co.,LTD,business mogel for testing instruments for more than 15 years.
Our engineers have been in this industry for over 15 years and served some of the most famous customers from all over the world.
We can provide below services for all our partners in this challenging world.
1.Fast delivery,1~5 days delivery time for Mestek Products.
2.Small MOQ requirements for all our items, 1PCS is also acceptable.
3.Exclusive Partnership in different regions
4.OEM&ODM Design services for bright ideals.
5.Free samples avaiable for partners.
All our items are coming with CE certification and we have special team work for after sales services 7*24 to help you solve any kind of problem.
We are ready for sign contract with you in case you need it, as honest dealer, we never crook our customers.
Come and let us make a difference together !
Our engineers have been in this industry for over 15 years and served some of the most famous customers from all over the world.
We can provide below services for all our partners in this challenging world.
1.Fast delivery,1~5 days delivery time for Mestek Products.
2.Small MOQ requirements for all our items, 1PCS is also acceptable.
3.Exclusive Partnership in different regions
4.OEM&ODM Design services for bright ideals.
5.Free samples avaiable for partners.
All our items are coming with CE certification and we have special team work for after sales services 7*24 to help you solve any kind of problem.
We are ready for sign contract with you in case you need it, as honest dealer, we never crook our customers.
Come and let us make a difference together !
