SA8064 Qualcomm Snapdragon 845 CPU Android 9 0 Промышленная материнская плата PCBA EDP
SA8064 Qualcomm Snapdragon 845 CPU Android 9 0 Промышленная материнская плата PCBA EDP

SA8064 Qualcomm Snapdragon 845 CPU Android 9 0 Промышленная материнская плата PCBA EDP


Поделиться:

Цена:299,00 $ - 399,00 $*
Стоимость в USD (на сегодня):Узнать

Количество:

Описание и отзывы

Характеристики



Product Description


Application Field
■ Commercial advertising display machine
■ POS machine
■ Digital photo frame advertising machine
■ Touch all-in-one machine
■ Self-service vending machine


Intelligent industrial POS motherboard, using eight-core Qualcomm Snapdragon 845 solution, clocked at 2.8GHz. Intelligent power management circuit supports commonly used external devices, rich interfaces and stable performance.

The board supports dual EDP and MIPI display output interfaces, supports 3G/4G data communication, WIFI/Bluetooth (supports 2.4G/5GWIFI) in one, supports currently popular video and picture format decoding, supports 4K, H.265 hard decoding.

Support single-channel and dual-channel EDP display, very suitable for commercial display advertising machine, POS advertising machine, touch all-in-one machine, etc.


Specifications


SA8064 Qualcomm Snapdragon 845 Android development motherboard PCBA
CPU
Qualcomm Snapdragon 845, Kryo385 8-core processor, Adreno 630G PU, clocked at 2.8GHz
RAM
DDR3 4GB, maximum support 8GB
ROM
EMMC FLASH 64GB can support 256G
Operating system
Android 9.0
Display interface
2 EDP interfaces, one MIPI screen interface
Dual screen display different contents
Support
Backlight voltage
Socket 12V output
Display voltage
2 channels 3.3V/5V/12V optional
Network
1 RJ45 Ethernet interface
1 wifi&BT module, support 2.4GHz and 5GHz WLAN wireless communication, sup port 802.11a, 802.11b, 802.11g, 802.11n and 802.11ac
and other standards. Support BT 4.2.
Support onboard 3G/4G
Support GPS.
TP
Support USB multi-point infrared touch, multi-point sound wave touch, multi-point optical touch. Also supports I2C communication
USB port
11*USB 2.0 (10*USB HOST, 1*USB OTG)
Serial port
3 UARTs (compatible and support RS232)
Other communication ports
1 I2C interface, can be controlled by GPIO port
External memory card
TF card, maximum support 256GB
Audio output
Left and right dual channel output, support 4R*3W dual speakers
Power input
1 external DC socket input,Built-in 1 DC12V output 4PIN PH2.54 socket
RTC
Support real-time clock, valid for 2 years
Timer switch
Support
System Upgrade
Support TF card / USB
Decoding
Support 1080P, 4K H.264/H.265 hard decoding
Support JPG, BMP, PNG and other image formats to browse and support

rotation / slidesFilm playback/picture zoom function
Video playback
Support wmv, avi, flv, rm, rmvb, mpeg, ts, mp4, etc.
Image Format
Support BMP, JPEG, PNG, GIF, etc.
Cash drawer box
1 RJ11 socket






Packing & Delivery




Our Company






Our Service




SZHRET features a one-stop solution that covers a wide range of POS products, where our customers may easily find everything they need including convenient after-sale services.

Based on the Principe of providing the most satisfaction, cost effectiveness is one of our competitive, You don't have to tolerate poor quality caused by budget limitation .We do lean production and count everything for you. As you can get every POS product from us, you can avoid high shipping fee generate from multiple orders.

HRET always keep up with the enterprise goal of "survival by quality, service for development". We are able to provide all customers with high quality products to meet their strict requirements at competitive prices. Ultimately we wish to establish and maintain a long-term relationship with every customer built on respect, confidence and Mutual benefit.



Company Certificate




FAQ


1. Can you accept OEM ?

Yes, we can develop POS frames as you request.

2. How can I get the touch POS terminal sample to check quality?
After price confirmation, you can order POS samples to check quality.

3. How long is your Lead Time ?
We have stock in black for each style. Sample is 1 days.
Bulk production is 3-15 days according to quantity and color request.

4. Is there cheap shipping cost to import to our country?
For small order, express will be best. And for bulk order, sea ship way is best but taking much time.
For urgent orders, we suggest via air to airport plus our ship partner send to your door.

5. How long is the warranty period?
Touch screen POS terminal warranty is 6 months.CPU ,main-board is 1 years.

6. Do you offer other relevant items?
Yes, we do. We are offering barcode scanner, thermal receipt printer, magnetic card reader, data collector and POS system.

7. If the goods are damaged badly, who is responsible for it?
We will be responsible for the damaged goods when it is damaged during transport, and we can exchange the new goods for you.

8. How do I know that you have sent the products out?
Once the products are sent out, a tracking number will be provided so that you can check where your goods at all times.
