Products Description
This machine is mainly suitable for turning pipe ends, taper pipe thread, pipe band, pipe sleeve, rod drilling and so on, It has characters of big power, good rigidity,high accuracy and excellent keep performance FANUC OR SIEMENS CNC system has been used, it is safe and reliable the reliability of the machine could be ensured, Pulse coder is as a measuring element, longitudinal and cross feed form semi-closed loop control.
Drilling and milling machine is a kind of small and medium-sized general metal cutting machine tool, which can mill both horizontally and vertically. It is suitable for drilling, reaming, reaming, boring and hole processing; for example, with disc milling machine, angle milling cutter, forming milling cutter and end milling cutter, it can mill plane, inclined plane, vertical plane and groove, etc. After installing the accessory end milling head, it can be used as multi-directional milling work.
Product parameter
Item | Parameter |
Max. Drilling dia (Steel/Iron) | 31.5/40mm |
Max.mill capacity(face/end) | 80/32mm |
Spindle taper | MT3/MT4/R8/ISO30 |
Worktable size | 730×210mm |
Worktable travelX/Y | 500/230mm |
Head tilt left right | 90° |
Spindle box swivel degree | 360° |
Spindle travel | 130mm |
Spindle nose to worktable | 470mm |
Spindle speeds(option) | 6steps:60Hz 90~1970rmp 50Hz 75~1600rmp |
Motor | 1.1kw |
N.W/G.W | 270/300KG |
Packing size(L×W×H,enclude foot) | 820×760×1150mm |
20'Container | 30 sets |
