16 мм переключатели светодиодное кольцо с подсветкой 5 контактов мгновенное фиксация ВКЛ./ВЫКЛ. 12 В кнопка водонепроницаемый металлический кнопочный
- Категории: Push Button Switches >>>
- Поставщик: Jiangxi,Shuangdu,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
Products Description
16mm switches led Ring Illuminated 5 pins Momentary Latching on off 12v pushbutton waterproof Metal Push Button Switch
Description:This metal push button switch is suitable for 16mm diameter mounting hole.
Used widely: Great for Power Button Switch, Led Switch, DIY projects or any circuit controls.
Specification:
Item Name: Push Button Switch
Action Type: Momentary / Latching
Head Shape: Flat Head
Contact: (1NO1NC)
Switch Rating: AC 250V 3A
Switch Color: Silver Tone
Lamp Voltage: 12V
Light Color: Blue
Thread Diameter: 16mm/0.63in
Material: Copper Nickel Plating or stainless steel
Product Paramenters
Detailed Specification | ||
Product type: | Waterproof Push Button Switch | |
Mounting diameter | 16mm | |
Head shape | Flat Head | |
Switch Combination | 1NO1NC | |
Operation type | Momentary / Latching | |
Max Current | 3A | |
Illuminating or Not | Yes | |
Voltage Available | 3V/5V/12V/24V/36V/110V/220V/250V | |
Housing material | Brass nickel,Stainless steel,aluminum oxide | |
Contact Resistance | 50mΩ max | |
Insulation Resistance | 1000MΩ Min | |
Dielectric Intensity | 2000VAC | |
Accessories | Nut, Rubber Waterproof O-ring | |
Installation Instructions
Details Images
Company Profile
Product packaging
FAQ
Q1. What is your terms of packing?
A: Generally, we pack our goods in neutral white boxes and brown cartons. If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.
Q2. What is your terms of payment? 12mm push button switch 12V LED PUSH BUTTON SWITCH 8mm switch
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q3. What is your terms of delivery? 16mm push button switch, 16mm led switch Momentary switch reset button switch
A: EXW, FOB, CFR, CIF, DDU.
Q4. How about your delivery time? push button switch 12V LED PUSH BUTTON SWITCH
A: Generally, it will take 3 to 10 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q5. Can you produce according to the samples? momentary switch on off SWITCH
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
Q6. What is your sample policy? moon off push button switch factorymentary switch on off SWITCH
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.
Q7. Do you test all your goods before delivery? on off push button switch factory
A: Yes, we have 100% test before delivery
Q8: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
A: Generally, we pack our goods in neutral white boxes and brown cartons. If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.
Q2. What is your terms of payment? 12mm push button switch 12V LED PUSH BUTTON SWITCH 8mm switch
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q3. What is your terms of delivery? 16mm push button switch, 16mm led switch Momentary switch reset button switch
A: EXW, FOB, CFR, CIF, DDU.
Q4. How about your delivery time? push button switch 12V LED PUSH BUTTON SWITCH
A: Generally, it will take 3 to 10 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q5. Can you produce according to the samples? momentary switch on off SWITCH
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
Q6. What is your sample policy? moon off push button switch factorymentary switch on off SWITCH
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.
Q7. Do you test all your goods before delivery? on off push button switch factory
A: Yes, we have 100% test before delivery
Q8: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
