Горячая продажа BW-250 портативный буровой насос высокого давления плунжерный для
- Категории: Oil Field Equipment >>>
- Поставщик: Shandong,Aolai,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
Products Description
Since the price of raw materials will fluctuate in different periods, the online price is a reference price, not the final price. But we can guarantee the same quality and the lowest price among our peers.
If you are interested in our products, please feel free to contact us, we will give you a real-time quotation as soon as possible
If you are interested in our products, please feel free to contact us, we will give you a real-time quotation as soon as possible
BW250 mud pump refers to a machine that transports mud and other flushing fluid into the borehole during drilling. Mud pump is an important part of drilling equipment. In the common positive circulation drilling, it is the surface flushing medium-clean water, mud or polymer flushing fluid under a certain pressure, through the high-pressure hose, faucet and the center hole of the drill pipe string directly to the bottom of the drill bit to achieve The purpose of cooling the drill bit and transporting the cut cuttings to the surface. The commonly used grouting machine is piston type or plunger type. The crankshaft of the pump is driven by the power machine to rotate, and the crankshaft drives the piston or plunger to reciprocate in the pump cylinder through the crosshead. Under the alternate action of suction and discharge valves, the purpose of pressure feeding and circulating flushing liquid is realized. The BW250 (high-pressure grouting pump) mud pump is a horizontal three-cylinder reciprocating single-acting piston pump with two cylinder diameters and four speeds. Displacement and hole depth can be adjusted freely according to the purpose. It can be used with a 1500-meter drilling rig, or can be filled with cement. The pump consumes less energy, is flexible in operation, durable, has good decomposability, and is easy to move.
Details Picture
According to the number of cylinders of the pump: according to the number of cylinders of the pump, there are single cylinder, double cylinder, three cylinder, five cylinder, etc. The main components of the slurry pump are composed of pump casing, pump body, impeller, pump seat, coupling, support cylinder, clutch, gearbox, power drive, motor seat, electric motor, pressure gauge, cleaning valve and other parts. The volute, pump seat, motor seat, and impeller nut are cast iron with good corrosion resistance and convenient processing technology. The impeller is three-piece single-circular-chord curved blades, semi-closed impellers and malleable cast iron are used, so it has high strength and corrosion resistance; it is easy to process, good through, and efficient. In order to reduce weight and reduce the amount of turning, the pump shaft is made of high-quality carbon steel cold drawn steel. The pump seat is equipped with four skeleton oil seals and shaft sleeves to prevent shaft wear and extend shaft life.
Product Specification
Product model: | 250 type |
Type: | Piston Pump |
Stroke length (mm): | 100 |
Bore diameter (mm): | 80 |
Pump speed (min-1): | 200 |
Flow rate (l/min): | 250 |
Pressure (MPa): | 2.5 |
Required power (Kw): | 15 |
Pitch diameter of V-belt pulley (mm): | 410 |
Input speed (r/min): | 500 |
Water absorption height (m): | 2.5 |
Inlet pipe diameter (mm): | 76 |
Drain pipe diameter (mm): | 51 |
Dimensions (mm): | 1100*995*650 |
Weight (Kg): | 760 |
Related Products
Our Company
Packaging And Shipping
Common Problem
FAQ
1: What kind terms of payment can be accepted?
A: For terms of payment, L/C, T/T, D/A, D/P, Western Union (can be) could accepted
2: What certificates are available in Machinery?
A: For the certificate, we have CE, ISO,EPA(USA),CCC
3: What about the delivery time?
A: 7-20 days after receiving the deposit.
4: What about the warranty time?
A: 12 months after shipment or 2000 working hours, whichever occuts first.
5. What about the Minimum Order Quantity?
A: The MOQ is 1 pcs
6.What about the service?
1). Quick response to every inquiry.
2). Professtional and detailed answer to any of customer's questions.
3). Strict QC and in time delivery.
4). Offer all relative material for customer to know and better use the machine.
5). Periodically after service follow up, offer any necessary support if needed.
6).For the new machine, within determined limits, the manufacture guarantees warranty for a period of 12 months after bought or 20
00 working hours(whichever comes first).
7).The warranty includes repairation or replace the parts for free which were proved to be defective in origin by the technical
department of the manufacture.
8).The repairation or replacement for the parts should not exceed the warranty period.
9).The warranty is valid on the condition of all the terms listed in the contract was observed.
1: What kind terms of payment can be accepted?
A: For terms of payment, L/C, T/T, D/A, D/P, Western Union (can be) could accepted
2: What certificates are available in Machinery?
A: For the certificate, we have CE, ISO,EPA(USA),CCC
3: What about the delivery time?
A: 7-20 days after receiving the deposit.
4: What about the warranty time?
A: 12 months after shipment or 2000 working hours, whichever occuts first.
5. What about the Minimum Order Quantity?
A: The MOQ is 1 pcs
6.What about the service?
1). Quick response to every inquiry.
2). Professtional and detailed answer to any of customer's questions.
3). Strict QC and in time delivery.
4). Offer all relative material for customer to know and better use the machine.
5). Periodically after service follow up, offer any necessary support if needed.
6).For the new machine, within determined limits, the manufacture guarantees warranty for a period of 12 months after bought or 20
00 working hours(whichever comes first).
7).The warranty includes repairation or replace the parts for free which were proved to be defective in origin by the technical
department of the manufacture.
8).The repairation or replacement for the parts should not exceed the warranty period.
9).The warranty is valid on the condition of all the terms listed in the contract was observed.
