Product Name | Liquid filter bag | ||
Material Available | Nylon | Polyester | Polypropylene |
Maximum Operating Temperature | 275-300℉(135-149℃) | 275-325℉(135-162℃) | 200-220℉(93-104℃) |
Micron Rating(um) | 25,50,100,150,200,300, 400,500,600(25-2000um) | 0.5,1,3,5,10,25,50,75, 100,125,150,200,250,300 | 0.5,1,3,5,10,25,50,75, 100,125,150,200,250,300 |
Size | 1# 7''*16''(18*43cm) 2# 7''*32''(18*81cm) 3# 4''*8.25''(10*23cm) 4# 4''*14''(10*38cm) 5# 6''*22''(15*55cm) | ||
Filter nag Are(m²)/Filter bag Volume(L) | 1# 0.25m²/8L 2# 0.5m²/17.5L 3# 0.09m²/1.5L 4# 0.15m²/2.5L 5# 0.25m²/8L | ||
Collar Ring | Polypropylene ring/Polyester ring/Galvanized steel ring/Stainless steel ring/rope | ||
Remarks | OEM support |
