High Quality Machinery 260t Crawler Crane QUY260 with Best

Item

Value

Remarks

Max. lifting capacity × Radiust × m

260×5

Deadweight with basic boomt

210

Main boom lengthm

20~83

Length of main boom with light boom headm

86~95

Fixed jib lengthm

12~30

Max. lifting capacity of fixed jibt

34

Offset angle of fixed jib°

10,30

Max. length of main boom with fixed jib m

77+30

Luffing jib lengthm

21~60

Max. lifting capacity of luffing jibt

73.5

Main boom angle under luffing jib working condition°

65,75,85

Max. length of main boom with luffing jib m

62+60

Max. speed of single rope on drum

Main winchm/min

110

The 6th rope layer

Auxiliary winchm/min

110

The 6th rope layer

ing winchm/min

29X2

The 6th rope layer

Luffing winchm/min

46

(Optional)

The 6th rope layer

Gradeability%

30

Ground pressureMPa

0.115

Overall dimensions (L×W×H)m

10.2×7.6×3.3

Without mast and boom frame

Engine

Rated power/ rotational speed kW/rpm

256/2100

Max. output torque/ rotational speedNm/rpm

1750/1200

Emission standard

TIER 3

Crawler gauge ×ground contact length ×track shoe widthmm

6400×8000×1200
