HKY 5V 4A 20W AC адаптер для POS-машины беспроводное зарядное
HKY 5V 4A 20W AC адаптер для POS-машины беспроводное зарядное
HKY 5V 4A 20W AC адаптер для POS-машины беспроводное зарядное
HKY 5V 4A 20W AC адаптер для POS-машины беспроводное зарядное
HKY 5V 4A 20W AC адаптер для POS-машины беспроводное зарядное
HKY 5V 4A 20W AC адаптер для POS-машины беспроводное зарядное
HKY 5V 4A 20W AC адаптер для POS-машины беспроводное зарядное
HKY 5V 4A 20W AC адаптер для POS-машины беспроводное зарядное
HKY 5V 4A 20W AC адаптер для POS-машины беспроводное зарядное

HKY 5V 4A 20W AC адаптер для POS-машины беспроводное зарядное


Поделиться:

Цена:*
Стоимость в USD (на сегодня):Узнать

Количество:

Описание и отзывы

Характеристики





O/P VOLTAGE
O/P CURRENT
Watt


Q46-U45W Max.
12.0 V
3.0 A
36.00 Watt
15.0 V
3.0 A
45.00 Watt
18.0 V
2.5 A
45.00 Watt
19.0 V
2.37 A
45.00 Watt


Input
100-240VAC, 50-60 HZ, 1.1A
AC Plug
EU/AU/US/UK/Korean/Cusomized for selection
Dc Connector
5.5*2.5mm/5.5*21mm/4.0*1.7mm/Custom
Case Dimension
L59.5 x W59.5 x H28.5mm
Efficiency
Meet CEC,Energy Star 3.0 CoC V5 Tier 2 DoE VI
Certificates
UL,cUL,CE,TUVGS,CB,FCC, Rohs, Erp
Warranty
3 Years Warranty
Package
Colorbox/Brownbox/OEM










Input
100-240VAC, 50-60 HZ, 1.1A (Max) Measured at 100Vac input and maximum load
Inrush: Current 50A
Empty loaded wasting: 75mW, 9V3A is less than or equal to 300mW
Output
9~20V Single Output to 45W
Power 45W Max
Load Regulation: ±5%
AC Plug/DC Tip
Dc Connector: 5.5*2.5mm/5.5*21mm/4.0*1.7mm/Custom
AC Plug: EU/AU/US/UK/Korean/Cusomized for selection
Efficiency
Meet CEC,Energy Star 3.0 CoC V5 Tier 2 DoE VI
Certification
UL,cUL,CE,TUVGS,CB,FCC, Rohs, Erp
Protection
OVP OCP SCP
Safety Standards
LVD: IEC60950-1/IEC62368, UL60950-1/UL62368-1, EN62368
EMC & EMI: EN55032 EN55035 EN61000-3-2 EN61000-3-3
FCC: EN55032 FCC Part15 Class B
Electrical
 Hi-Pot Test: AC 3000V1min between input plug-DC plug
Leakage current : 0.25mA max at nominal AC input voltage and frequency
Protection Class: Class II
Mechanicals
 Case Dimension: L59.5 x W59.5 x H28.5mm
Dimension
UK (B)93 x 59.5 x 30mm
EU (V)96.5 x 59.5 x 30mm
US (U)75.5 x 59.5 x 30mm
AU (S)84.8 x 59.5 x 30mm
Cable: UL 1185 # 18AWG # 20AWG , 1750mm
Case MaterialUL94-V1
Environmental
Operation Temperature: -10 °C – 40 °C
Storage Temperature: -25 °C – 70 °C
Operation Humidity: 5%( 0°C) ~
Storage Humidity: 5%~ 95%
Usage
For monitor, led light, etc. for notebook, ultrabook, monitor, mini pc, tablet, etc,. For ASUA Ultrabook, for DellHP, Ultrabook,
Monitor, Tablet, for Samsung, for ASUS, for Acer, for LG, for Sony, for Lenovo/Toshiba,etclaptop














1. Who are we?
We are based in Guangdong, China, start from 2013,sell to North America(30.00%),South America(20.00%),Western Europe(10.00%),Northern Europe(10.00%),Eastern Europe(5.00%),Southern Europe(5.00%),Oceania(2.00%),Domestic Market(2.00%),Africa(1.00%). There are total about 201-300 people in our office.

2. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.What can you buy from us?
Power Adapter,Power Supply,Laptop Charger,USB TYPE C PD Charger,Car Charger

4. Why should you buy from us not from other suppliers?
Products: 5V to 54V upto 330 Watt
Certificates: UL TUV GS CB PSE SAA CE FCC ROHS REACH DOEVI
Warranty: 3 years

5. What services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FCA,DDP,DDU,Express Delivery；
Accepted Payment Currency:USD,EUR,AUD,CNY;
Accepted Payment Type: T/T,Western Union;
Language Spoken:English,Chinese,Spanish




Amy Zhang
Sales Manager
Shenzhen Huikeyuan Co., Ltd.
深圳市匯科源電子科技有限公司
BLK 3,Guiyue Rd 308,Longhua Shenzhen 518000 CN
Mob/Whatsapp: +86-13632726580
Tel: +86-0755-8521-9212, ext. 818
Email: amy@szcathedy.com
www.hkypowersupply.com | www.hkypower.eu
