Полноприводной трактор Foton Lovol 3 тонн фронтальный погрузчик FL936F-II с ведром для
- Категории: Loaders >>>
- Поставщик: Oriemac,Machinery,&,Equipment,(Shanghai),Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
Product Description
Foton Lovol 3 Ton Front Wheel Loader FL936F-II with Bucket for Sale
Operating weight:10070kg
Bucket capacity:1.8cbm
Total cycling time:10.5s
Engine power:92kw
Max digging force:120kn
Specification
Major Parameter | ||
Rated Load (kg) | 3000 | |
Operating Weight (standard configuration)(kg) | 10070 | |
Rated Bucket Capacity (m³) | 1.8 | |
Maximum Digging Force (KN) | 120 | |
Maximum Traction (KN) | 92 | |
Total Cycling Time (s) | 10.5 | |
Maximum Dumping Height (mm) | 2980 | |
Maximum Dumping Distance (mm) | 1100 | |
Forward Speed Range (km/h) | 0~37 | |
Backward Speed Range (km/h) | 0~28.5 | |
Transportation Clearance (length*width*height)(mm) | 7150*2424*3230 | |
Maximum Steering Angle (°) | 36 | |
Maximum Climbing Capacity (°) | 30 | |
Minimum Turning Radius (mm) | 6005 | |
Tyre Specification | 17.5-25-12PR | |
Engine Parameter | ||
Model | Weichai WP6G125E22 | |
Type | 6-cylinder, in-line, direct injection , turbocharge | |
Power (kw) | 92 | |
Maximum Torque (N.m) | 460@1400-1600 | |
Cylinder Diameter (mm) | 105 | |
Distance of Travel (mm) | 120 | |
Output Volume (L) | 6.234 | |
Fuel Oil Consumption (g/kw.h) | 220 | |
Hydaulic System | ||
Pressure of Working System (Mpa) | 16 | |
Type of Motor Braking System | Single pipeline gas-oil 4-wheel clipper disc braking | |
Type of Parking/Emergency Braking System | Clipper disc braking | |
Fuel Tank Capacity | ||
Fuel Oil Tank Capacity (L) | 155 | |
Hydraulic Fuel Tank Capacity (L) | 180 | |
Product Show
