Новый Умный мягкий стартер двигателя беличьей клетки 45 кВт переменного тока для водяного насоса очень хорошее качество длительное

Brand

STA

Product Name

Squirrel cage asynchronous Motor Soft starter

Power Supply

Urban power,self-provided substation,dieel generating sets

power

7.5KW-600KW

Voltage

AC380V/AC660V/AC1140V 50Hz

Display

Digital /LCD

Phase

Three Phase

Soft start time:

1~120S

Soft stop time:

1~15S

Rated operational current

15~1200A

Start frequency

Less than 20times per hour

Cooling

naturalair-cooling or fan air cooling

IP

20

Environment

if the altitude is above 2000m,user should select the higher power equipment

Environment

Temperature:

-25℃ TO+40℃

Relative humidity

≤95%

Indoor install

non-condensing,no inflammable,explosive gases,no conducive dust

Vibration is less than

0.5G

Stop

free stop and soft stop

Starting modes

 Current limiting starter, Voltage ramp start , Kick start +current-limiting start, kick start +voltage ramp start . Current ramp start . Voltage current-limiting double closed –loop start.

Protect content

Over current , Overload , Open phase, instantaneous stop and other fault protection .with the flow, over loading, lack phase, instantaneous stop, and other malfunction protection.

Install

 Wall mounted

Overload protection:

IEC60947-4-2standard
