Main Advantage:
1. Standard 700lines, effective pixels is 795(H)*596(V).
2. Camera head waterproof: IP8X, to prevent water from entering the camera head during the surgery (Low temperature plasma and soaking disinfection is available).
3. Geometric distortion and the ability for color rendition has been tested qualified by related organization.
4. Multi-output : USB, BNC, AV, can connect to medical monitor, laptop and TV.
5. Extinction speed is less than 0.2s.
6. The resolution of endoscope camera is up to 700lines.
7. Supports Windows XP, 7, 8, &10
8. With menu button to adjust parameters
Image sensor | 1/3 CCD |
Language | English |
Effective pixels | P:795(H)*596(P) |
Scanning frequency | N:60HZ P:60HZ |
Scan mode | Interlacing scan |
Horizontal resolution | 700TVL |
Digital zoom | 0-60x |
DNR | 3D Denoise |
SNR | ≥50dB |
Output port | USB, BNC, AV |
Brightness | ODS adjustable |
DSS |
