Электромагнитный клапан LENC DEVG15 24 В для газовой

Product details

This gas solenoid valve can be widely used in the field of gas safety transmission control to provide gas supply for opening and closing or emergency cutting.

It can be applied to media such as natural gas, methane, liquefied petroleum gas, etc.

Features: adjustable opening time and adjustable flow.

Operation and installation

Normally closed, it will open quickly when power is on; the blue indicator lights up after the valve is operating. It will be closed immediately when the power is off and the indicator lights off. For the first time, you can re-adjust the factory setting mode state when the power is on, adjust the opening time and the size of the back-end output flow, as well as the fast-open or slow-open section within the open range.

There are bypass holes on both sides and bottom of the valve body, and the diameter is G 1 / 4"

Technical parameter

Opening time 1-30 seconds adjustable

Closing time< 1 second

Maximum operating frequency: 20 times/ min

Maximum working pressure:

ON 10- 25 360 mbar; DN 32 - 50 200 mbar

With G/4 aperture bypass hole

Built-in filtering

Protection level: I P54

Standard and certification

Achieving "A" standard

Meet European gas standards

CE certification

Electrical specification

Rated voltage: 50 I 60 Hz, 230 VAC,110 VAC,24 VDC(and other specific)

Coil level F, can be 360° rotation, can work 100% continuously for a long time.
