F-204781 Cylindrical Roller Bearing F-204781.RNN 40*61.74*35.5mm Rexroth Reducer Bearing

F-204781 Cylindrical Roller Bearing F-204781.RNN 40*61.74*35.5mm Rexroth Reducer Bearing have the maximum amount of rollers. Because of this Cylindrical Roller Bearings are very rigid and have a high load capacity. Cylindrical Roller Bearings are constructed with an inner and an outer ring with in-between cylindrical rollers which are guided by rings.

Full complement cylindrical roller bearings are mainly used in the need to withstand large radial loads and low speed of the occasion, in the lower rotary can withstand shock loads and moment loads, double row full complement cylindrical roller bearings at the factory pre good fats, can be installed directly used, the outer ring with a seal to prevent leakage of grease and impurities to enter, mainly used in lifting machinery, port machinery parts or walking connections.



We widely supply below types of Hydraulic pump spindle bearing :

NUP50*90*23,RNU35.555*57*22,RNU42.01*72*30,F-201346,F-202578,F-58786,RNUP0709V,F-204754,F-84874,F-219012,F-219590,F-219593,F-554377,F-208098,F-208099,F-204781,F-204782,F-204783,F-208101,1040-08,R916411718,R916411717,1160-22,RNNX10V,F-212543,RNNX22AV,CPM2518,CPM2590,CPM2593,CPM2179,



F-204781 Cylindrical Roller Bearing F-204781.RNN 40*61.74*35.5mm Rexroth Reducer Bearing data for reference :

Cylindrical roller bearings can provide axial guidance of the planet.This can be carried out by means of axial washers and retaining rings arranged on both sides of the rolling element .The bearings are available as single row and double row locating bearings. They can support not only high radial forces but also axial forces in both directions and can therefore guide shafts axially in both directions.The bearings are supplied in an open design. They are not greased and can be lubricated with oil or grease.The rolling elements are protected against damage and loss during transport by means of a plastic sleeve.



Product name	F-204781 Cylindrical Roller Bearing F-204781.RNN 40*61.74*35.5mm Rexroth Reducer Bearing
Series	F-204781 F-204781.RNN
Brand name	SYBR / GERMANY / OEM
Size	40*61.74*35.5 mm mm
Outer diameter	61.74 mm
Bore size	40 mm
Width	35.5 mm
Weight	0.3 kg
Material	Chrome steel
Cage	Steel cage
Clearance	Standard
Quality	ISO9001:2008
Service	OEM customized service
Product advantage	1.High-load with high-end technology and low-noise;   2.Long-life with high quality;   3.Competitive price and OEM service;
Application	Auto Machinery,etc.



Bearing No.	Weight(kg)	d(mm)	Dr(mm)	B(mm)
F-227932	0.12	20	36	30
F-219593	0.144	25	42	30
F-204045	0.27	30	49	34
F-219590	0.28	35	55	36
F-123243	0.4	45	66	40
F-210408	0.46	50	72	40
HS-262	0.86	55	83	46
RNNX22AV	0.895	60	86	46
F-24*40.3*26	0.94	65	93	46
RNN3005X3V	1.12	70	100	54
F-217615	1.35	75	107	54
F-210304	1.8	80	116	60
RNN306X3V	1.85	85	121	60
F-32*46.6*28	2.6	90	130	67
F-208098	2.6	100	139	67
RNN3007X3V	3.95	110	156	80
F-385328	4.52	120	167	80
HS-263	6.7	130	183	95
RNNX10V	7.914	140	197	95
F-237005	8.215	150	206	100
F-229575.1	11.09	160	224	109
567079B	15.6	170	242	122
