HG-CF Chemistry Free UV-CTP Plate
HG-CF is the latest product with unique technology in the field of ultraviolet computer to plate. Light sensitive coating with chemistry-free processing variables deliver the options of plate making from either development on press or development in low chemistry solution. With HG-CF, one can be more competitive, reduce cost, gain efficiency and achieve“green” printing.
Technical Specifications
Plate Type | Negative-working, no process required, ultraviolet sensitive digital plate |
Application | Commercial, newspaper and packaging print applications |
Substrate | Electrochemical grained and anodized aluminum substrate |
Gauge | 0.15mm,0.2mm,0.24mm, 0.3mm and 0.4mm availability in selected regions. |
Spectral sensitivity | 405nm |
Coating Colour | Light Blue |
Exposure energy required | 20-40mj/cm2, dependent on image type, configuration and resolution. |
Resolution | 1-99%@200lpi or 25μ stochastic ( depend upon capability of imaging device.) |
Developer | No required |
Run length | Up to 100,000 impressions,Depend upon image resolution, press, press chemistry, ink, and paper conditions. |
Safe-light | Yellow light |
Shelf life | 12 months, under recommended storage conditions |
Storage conditions | temperature:18-25 C, RH: 30-60% |
