Product Description
Automatic Cartoning machine
Automatic Box vertical cartoning Machine
1.It is specially design to pack small quantities multi size box.
1.It is specially design to pack small quantities multi size box.
2.With low cost and only require small area. It is suitable for various sizes of box. The machine is a vertical type with multiple function and require a short time to change mould.
3.304 stainless steel case
4.Advanced PLC Control System Combined with 5.7” Colorful Touch Screen Control Panel , can easily set and change the packing parameters.
4.Advanced PLC Control System Combined with 5.7” Colorful Touch Screen Control Panel , can easily set and change the packing parameters.
Production speed: | 20-50box/min | ||
Paper box's largest size | 200*80*80mm | ||
Paper box's smallest size | 60*20*20 mm | ||
Paper quality of carton | 250-350g/m3 | ||
Motor horsepower | 1/4HP 15:1 1.5KW/H | ||
Power supply | 220V 50/60HZ single phase | ||
Machine noise | ≤80dB | ||
Gas source | 0.5-0.8 Mpa | ||
Compress air consumption | 260L/min | ||
Machine measurement: | L 1100 x W 1500 x H 1700 mm | ||
Machine weight | 450Kg | ||
Machine function and characteristic
1.The machine integrated with electrical ,pneumatic, mechanical , working stable and reliable ,three cams design is the newest
innovative and had patent and CE approved .2.It devices with imported components ,such as omron temperature controller,risk
bearing. and all frame are made by ss 304.
3.It uses inverter to control the speed, so could adjust according to the operation need.
4.The mould change easy ,without dismantle drive chain ,hopper .save time greatly
5.New type double safeguard construction , won't broke machine parts for any incident .
6.One way hand wheel prevent from backward operation, and protect worker's safety when the machine operates for still hand wheel.
7.New type dual cutting knife replace traditional single knife, so could use for very long time.
1.The machine integrated with electrical ,pneumatic, mechanical , working stable and reliable ,three cams design is the newest
innovative and had patent and CE approved .2.It devices with imported components ,such as omron temperature controller,risk
bearing. and all frame are made by ss 304.
3.It uses inverter to control the speed, so could adjust according to the operation need.
4.The mould change easy ,without dismantle drive chain ,hopper .save time greatly
5.New type double safeguard construction , won't broke machine parts for any incident .
6.One way hand wheel prevent from backward operation, and protect worker's safety when the machine operates for still hand wheel.
7.New type dual cutting knife replace traditional single knife, so could use for very long time.
Company Profile
FAQ
Q1 : Which one packing machine is suitable for us ?
Dear, before quoting, please kindly consult us and providing: 1.your product name,product picture. 2.your bag size,such as bag width and bag height. 3.ideal bag shape. For there is over 100 kinds of packing machine,different on bag size. In order to recommend u the best,we need know that information. If u just start this business,no bag size,we can help u to find similar weight bag for your reference.
Q2: Is that packing machine ok for our product?How to operate it?
If you donnot mind,you can send u sample.we will use existing packing machine to test for u. During that time,we will take video and clearer picture for you.If chance,we can take video online and show u.
Q3: Is that pack many bag size in the same packing machine?
That is the common question from our customer.Every packing machine has its range for bag length and bag width.Can you send us full details,i will calculate for u and give u exact reply.
Q4:How can I trust you for the first time business ?
Please note our above business license and certificate. And if you don't trust us, then we can use Alibaba Trade Assurance
service. it will protect your money during the whole stage of transaction.
Q5: Can you explain me the whole transaction process ?
1.Both sides reached cooperation intention
Dear, before quoting, please kindly consult us and providing: 1.your product name,product picture. 2.your bag size,such as bag width and bag height. 3.ideal bag shape. For there is over 100 kinds of packing machine,different on bag size. In order to recommend u the best,we need know that information. If u just start this business,no bag size,we can help u to find similar weight bag for your reference.
Q2: Is that packing machine ok for our product?How to operate it?
If you donnot mind,you can send u sample.we will use existing packing machine to test for u. During that time,we will take video and clearer picture for you.If chance,we can take video online and show u.
Q3: Is that pack many bag size in the same packing machine?
That is the common question from our customer.Every packing machine has its range for bag length and bag width.Can you send us full details,i will calculate for u and give u exact reply.
Q4:How can I trust you for the first time business ?
Please note our above business license and certificate. And if you don't trust us, then we can use Alibaba Trade Assurance
service. it will protect your money during the whole stage of transaction.
Q5: Can you explain me the whole transaction process ?
1.Both sides reached cooperation intention
2.Signed the Contract
3.Arrange the 30% deposit to factory
4.Factory arrange production
5.Testing&detecting the machine before shipping
5.Testing&detecting the machine before shipping
6.Arrange the balance payment
7.Confirm the shipping details then delivery
8.When the machine arrives, follow the instructions
Q6: How do we contact you?
There is a contact information on the right of this page. Please leave message and click "send". you also can contact us through Email, wechat, skype, whatsapp, QQ, Facebook, phone and etc.
Q6: How do we contact you?
There is a contact information on the right of this page. Please leave message and click "send". you also can contact us through Email, wechat, skype, whatsapp, QQ, Facebook, phone and etc.
Packing & Delivery
