Product Description
Geneal purpose micro switches are used in AC control circuits of 50 or 60Hz, with a voltage up to 380V and rated control capacity of 100VA or in DC control cirucits with a voltage up to 220V and a rated control capacity of 10W.
Specification
Operation Speed | 0.01mm-1m/s | ||||||
Operation Frequency | Mechanical: 240 operations/minute; Electircal: 20 operations/minute | ||||||
Contact Resistance | 15Ω max.(initial value) | ||||||
Insulation Resistance | 100Ω min.(at500VDC) | ||||||
1000VAC, 50/60Hz for 1 minute between terminals of the same polarity | |||||||
1500VAC, 50/60Hz for 1 minute between current-carrying and non-current-carrying metal parts | |||||||
1500VAC, 50/60Hz for 1 minute between each terminal and ground | |||||||
Vibration | 10-55Hz, 1.5mm double amplitude | ||||||
Shock | Mechanical Durable: 1,000m/s²(about 100G,S); Malfunction: 300m/s²(about 30G,S) | ||||||
Ambient Temperature | General purpose type: -25 to +80℃; Sealed type: 95% RH max. | ||||||
Humidity | General purpose type: 85% RH max.; Sealed type: -15 to +80℃ | ||||||
Life | Mechanical: 20,000,000 operation above; Electrical: 500,000 operation above | ||||||
Weight | About 22 to 58g | ||||||
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
FAQ
1,Q:Why your quotation is higher than some other suppliers?
A:In domestic market, the high and low quality brands are mixed together. There are many low-cost micro switch which is actually assembled with some cheaper and unstable parts, it crudely, to reduce costs and use of substandard components for assembly, there is a very big security risk! In order to protect the pro personal and property safety, please do not covet low price, be sure to choose a reliable supplier!
..............................................................................................................................................................
2,Q:How many years quality warranty you can offer?
A:We promise to give customer 1.5 years warranty since we ship the goods,our warranty time is longer than most of competitors.
3,Q: Can I get some samples?
A: Yes,sample order is available for quality check and market test.
4,Q: What’s the delivery time?
A: It usually takes about 2-5 working days for small sample order and 10-35 days for big order.
A:In domestic market, the high and low quality brands are mixed together. There are many low-cost micro switch which is actually assembled with some cheaper and unstable parts, it crudely, to reduce costs and use of substandard components for assembly, there is a very big security risk! In order to protect the pro personal and property safety, please do not covet low price, be sure to choose a reliable supplier!
..............................................................................................................................................................
2,Q:How many years quality warranty you can offer?
A:We promise to give customer 1.5 years warranty since we ship the goods,our warranty time is longer than most of competitors.
3,Q: Can I get some samples?
A: Yes,sample order is available for quality check and market test.
4,Q: What’s the delivery time?
A: It usually takes about 2-5 working days for small sample order and 10-35 days for big order.
