Types of Geogrid for Driveways Construction in Columbia
Types of Geogrid Product Introduction:
Types of Geogrid is made of high molecular polymer after extruded and laminated and punched into regular mesh before longitudinal stretching.
The material on the longitudinal and transverse has great tensile strength, this kind of structure in the soil can also provide a more effectively undertake the chain and the spread of the thought system, suitable for large area of permanent bearing foundation reinforcement.
Types of Geogrid for Driveways Construction in Columbia TGSG 15-15
![]()
| Item | TGSG 20-20 | TGSG 25-25 | TGSG 30-30 | TGSG 35-35 | TGSG 40-40 | |
| Tensile strength (KN/m) | Longitudinal | ≥20 | ≥25 | ≥30 | ≥35 | ≥40 |
| Transverse | ≥20 | ≥25 | ≥30 | ≥35 | ≥40 | |
| Longitudinal | ≤13 | ≤13 | ≤13 | ≤13 | ≤13 | |
| Transverse | ≤16 | ≤16 | ≤16 | ≤16 | ≤16 | |
| Longitudinal | ≥8 | ≥8 | ≥11 | ≥12 | ≥13 | |
| Transverse | ≥10 | ≥11 | ≥13 | ≥14 | ≥15 | |
| Longitudinal | ≤10 | ≤11 | ≤15 | ≤15 | ≤16 | |
| Transverse | ≤13 | ≤13 | ≤15 | ≤18 | ≤20 |
Types of Geogrid for Driveways Construction in Columbia Application:
Make reinforce treatment for various kinds of soft soil foundation to evenly distribute load stress and reduce uneven settlement, not easy to generate static electricity, and flammability property good in the coal mine. It is easy to wash coal.
Used in highway, railway, port, airport and municipal project. Support in the recovery working face of coal mine and roadway in the coal mine.
Used in highway, railway, port, airport and municipal project. Support in the recovery working face of coal mine and roadway in the coal mine.
Types of Geogrid for Driveways Construction in Columbia Function:
1. Improving bearing capacity of road foundation and prolong its service life
2. Preventing road surface from subsiding and cracking
3. Be convenient for construction, reducing cost and maintaining expense for the project
4. Providing stability for slopes and avoid the losing of the water and soil
Types of Geogrid for Driveways Construction in Columbia Certifacation:
Case
Unixial Plastic Geogrid for Driveways Construction in Ghana
The unixial plastic geogrid for driveways is formed by extruding high molecular polymer into a thin plate, punching a regular mesh, and then stretching it longitudinally. In this process, the polymer becomes an oriented linear state and forms an oblong network integral structure with uniform distribution and high node strength. This kind of structure has quite high tensile strength and tensile modulus, especially our company’s products of this kind have a high early stage (elongation between 2%-5%) tensile strength and tensile modulus that exceed the international level. The unixial plastic geogrid for driveways provides the soil with an ideal interlocking system of force bearing and diffusion. The e unixial plastic geogrid for driveways has high tensile strength (>150Mpa), adapts to various soils, and is currently a widely used reinforcement material.
With its unique anti-leakage performance, the uniaxial plastic geogrid for driveways has been widely used in civil engineering such as water conservancy, environmental protection, transportation, railway, and civil aviation. Basic treatment and capping of waste landfills, anti-seepage of artificial lakes, reservoirs, channels, rivers, roof gardens, and anti-seepage of famous underground structures such as basements, subways, tunnels, and underground passages. The unixial plastic geogrid for driveways has changed the ordinary joints with small peeling force (30N) and easy soldering. Cracking, causing difficulty in construction, reducing the effect of preventing side displacement and other shortcomings, and further improved products.
The technical indicators of the unixial plastic geogrid for driveways shall meet the design requirements. When laying, the surface of the soil layer should be flat, and hard protrusions such as broken stones and stones are strictly prohibited. When laying, the surface of the geogrid should not be wrinkled. The geogrid shall be fixed on the surface of the filling layer by manual tensioning and nailing.
Specifications of Unixial Plastic Geogrid for Driveways Construction in Ghana
- Model- TGSG20-20
- Total Geogrid Quantity- 24,000 Square meters
- Roll Size- 2m*50m
About BPM:
BPM had provided many types of effective and states of the art geomembrane and other geosynthetics to over 36 countries. Our main customers are from Australia, France, Sweden, UK, Hong Kong, Hungary, New Zealand, Poland, Mexico, Ecuador, Brazil, Ghana, Bangladesh, Thailand, Vietnam, Malaysia, Indonesia, Singapore, Philippines, Sri Lanka, India, UAE, Saudi Arabia, Qatar, Kenya, Ghana, Ethiopia, Somalia, Nigeria, South Africa, Swaziland, Mongolia etc.
BPM is not only manufacturing best quality geomembrane products but also providing professional design and installation service. OEM, ODM, custom development and fabrication are also available. If you have any questions or inquiries, please fill and submit the following form, we will reply as soon as possible.
FAQ
Q1. Can you do OEM?
A1. Yes.of course.We can produce the products as per your request.
If you can offer samples to us,it will be more convenient.
Q2. If I want to order a small quantity goods,can you do it?
A2. If the product you need we have stock available,that would be great,you can choose the instock goods.
but if not, don’t worry, we can take your order with our other clients’ order to be produced together.
But it needs to wait some time .
Q3. Can I get a sample from your company?Should I pay for the express fee?
A3. If you can accept our available sample,we can offer free sample to you.
If you want a customized sample,we can renegotiate the cost.
About the express fee,please offer a freight collected account and pay for the express fee by your side.
After confirming your order, the sample’s freight cost will be deducted from your order’s total cost.
Q4. How will you follow my order?
A4. When the goods are started to produce,we will take photos for the goods and send it to you.
If you find any production deficiencies,please contact us to correct it.
We will keep in touch with you in the whole production by e-mail or instant messaging, like Skype/Viber/WhatsApp, you can get the latest news about your order.
After the goods are finish,we will take photos for the goods and packing to you before shipping.
Q5. What is your exporting countries?
A5. We have good sales performance and win good international reputation in more than 30 Countries and
regions,such as Japan, America, Australia,Russia, Canada,Middle East and so on.
Especially in the Middle East and Australia market.
