Новый блок питания HKY для ноутбука 8 В до 48 тонкий настольный Acer Asus Toshiba Dell Lenovo
Новый блок питания HKY для ноутбука 8 В до 48 тонкий настольный Acer Asus Toshiba Dell Lenovo
Новый блок питания HKY для ноутбука 8 В до 48 тонкий настольный Acer Asus Toshiba Dell Lenovo
Новый блок питания HKY для ноутбука 8 В до 48 тонкий настольный Acer Asus Toshiba Dell Lenovo
Новый блок питания HKY для ноутбука 8 В до 48 тонкий настольный Acer Asus Toshiba Dell Lenovo
Новый блок питания HKY для ноутбука 8 В до 48 тонкий настольный Acer Asus Toshiba Dell Lenovo
Новый блок питания HKY для ноутбука 8 В до 48 тонкий настольный Acer Asus Toshiba Dell Lenovo

Новый блок питания HKY для ноутбука 8 В до 48 тонкий настольный Acer Asus Toshiba Dell Lenovo


Поделиться:

Цена:*
Стоимость в USD (на сегодня):Узнать

Количество:

Описание и отзывы

Характеристики





Model
Specification
Hot selling Model







A12-2
Output: 12V -24V

Power: 65W Max.

IEC-320-C6

Certificates: TUVGS CE CB UKCA FCC RoHs  ERP
19V3.42A
19.5V3.33A
20V3.25A
Output:  9V -54V

Power: 65W Max.

IEC-320-C8

Certificates: UL TUVGS CE CB PSE SAA RCM UKCA FCC ERP RoHs
12V5A
 15V4A
 16V4A
 18V3A
 19V3.42A
19.5V3.33A
20V3.25A
 24V2.7A
48V1.35A


INPUT CHARACTERISTICS
Rated Input Voltage ----------------------------------- 100-240V AC
Rated Frequency ---------------------------------------- 50/60Hz
Steady AC Current -------------------------------------- 1.5A (Max) Measured at 100Vac input and maximum load
Inrush Current --------------------------------------------- Less than 80A
Empty Loaded Wasting ------------------------- 150mW

SAFETY STANDARDS
LVD ---------------------------------------- UL60950-1 UL62368-1 EN62368-1 IEC62368-1 EN60950-1
EMC & EMI ----------------------------- EN55032 EN55024 EN61000-3-2
EN61000-3-3


RELIABILITY ITEMS
Hi-Pot Test ------------------------- AC 3000V1min between input
Plug-DC plug
Leakage Current ------------------- 0.25mA Max at nomimal AC input Voltage and frequency
Temperature Rise --------------------- Case surface rise 95 ℃ or Less
OUTPUT CHARACTERISTICS
Power ---------------------------------------------------------------- 65W Max
Load Regulation ------------------------------------------------- ±5%
Turn on delay time ------------------- 3s Max at AC 115V, Max output load
Hold up time --------------------------- 5ms Min at AC 115V, Max output load
Rise up time ------------------------ 40ms Max at AC 115V, Max output load
Efficiency ------------------------------- Meet CEC, Energy Star 3.0
(EPA/DOE-LevelVI)

PROTECTION
Over Voltage Protection ---------------------------------------- Auto Recovery
Short Circuit Protection ---------------------------------------- Auto Recovery
Over Current Protection ---------------------------------------- Auto Recovery
Protection Class ------------------------------------------------- Class II

ENVIORNMENTAL
Operation Temperature -------------------------- -10 ℃ - 40 ℃
Storage Temperature ---------------------------- -25 ℃- 70 ℃
Operation Humidity ------------------------ 5% (0 ℃) ~ 90% (40℃)
Storage Humidity --------------------------------------------- 5% ~ 95%













1. who are we?
We are based in Guangdong, China, start from 2013,sell to North America(30.00%),South America(20.00%),Western Europe(10.00%),Northern Europe(10.00%),Eastern Europe(5.00%),Southern Europe(5.00%),Oceania(2.00%),Domestic Market(2.00%),Africa(1.00%). There are total about 201-300 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Power Adapter,Power Supply,Laptop Charger,USB TYPE C PD Charger,Car Charger

4. why should you buy from us not from other suppliers?
Products: 5V to 54V upto 330 Watt
Certificates: UL TUV GS CB PSE SAA CE FCC ROHS REACH DOEVI
Warranty: 3 years

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FCA,DDP,DDU,Express Delivery；
Accepted Payment Currency:USD,EUR,AUD,CNY;
Accepted Payment Type: T/T,Western Union;
Language Spoken:English,Chinese,Spanish
