1.Product introduction:
Air-cooled condenser is a kind of cooling equipment that is used in the cooling equipment of Foung. There are mainly four types of air-cooled condensers produced by our company: FNH type, FNV type, FNVB type, GP type, FNH type, side blowing type, FNV type, FNVB type, FNU type and GP type.
2.Product features as follows：
● High-quality steel shell, the surface spray, corrosion-resistant, beautiful appearance;
● The coil adopts the copper tube mis-arranging way, utilizes the mechanical expansion tube to make the copper tube and the fins closely combine, and the heat exchange effect is good;
● products after 2.5MPa tightness test and system sewage treatment;
● Applicable to R22, R134a, R404a, R407c and other refrigerants;
● FNU-type condenser with large windward side, good heat transfer, are equipped with low-noise motor;
● High-performance heat exchange coil, clean and dry;
Adopt FZL series axial flow fan, air volume, low noise, low power consumption;
● shell with high-quality galvanized sheet, spray treatment, corrosion-resistant durable;
● Special-purpose products, please contact the company's sales department.
3.Parameters



Model
Fans
Fan

Into tube
(mm)

Back tube
(mm)
Power
(w)
Air-Volume
(m³/h)
Diameter
(mm)
Voltage
FNU-50
2
380
7000
400
220/380
19
16
FNU-60
2
380
7000
400
220/380
19
16
FNU-70
2
500
10400
450
220/380
22
16
FNU-80
2
500
10400
450
220/380
22
16
FNU-90
2
840
13000
500
220/380
25
19
FNU-100
2
840
13000
500
220/380
25-22
19
FNU-110
2
840
13000
500
220/380
25-22
19
FNU-120
2
1100
15000
550
220/380
28-25
22
FNU-130
2
1100
15000
550
220/380
28-25
22
FNU-135
2
1100
15000
550
220/380
28-25
22
FNU-140
2
1600
19000
600
220/380
28-25
22
FNU-150
2
1600
19000
600
220/380
28-25
22
FNU-160
2
1600
19000
600
220/380
32-28
25
FNU-170
2
1720
21600
630
220/380
32-28
25
FNU-180
2
1720
21600
630
220/380
32-28
25










Henan Tianneng Refrigeration Technology Co.,Ltd., one of professional manufacturers which is dedicated to research and development, production and marketing of refrigeration equipment , was established in 2015. It is located in Puyang City, Henan province. Our company, covers an area of 11,000 square meters, has invested more than 150 million CNY and has more than 130 professional and excellent staffs.We are specialized in air evaporator,which includes DD, DJ, DL series in different temperatures. And we also produce air condenser, which contain FNH series,FNV series,FNVB series,FNVT series and FNU series.Using the special arrangement coils and reasonable structure, the aluminium fins is fitted on the Copper tube by mechanical expansion.Selecting high-efficiency fan with large air volume, the air evaporator has long range, low power consumption, low noise and long service life. The electric heating pipe with high-quality stainless steel evenly distributes in the coil. The unit cooler has short defrosting time and perfect effect.Making non-standard products due to the the customers’ demands.
By using professional product testing methods and according to the different market demands , Tianneng can supply customers and distributors all over the world the stable quality and professional cooler equipment. Our customers are from all over the world. We also provide warranty and after-time services. We are willing to become your partners with high quality products. Welcome to visit our plant!
