Model | Unit | four-wheel drive | ||||
Type | 4×4Wheel | |||||
Calibration traction | kN | 9.5 | ||||
Power output shaft maximum power | kw | 28.2 | ||||
Shape | Long (front counterweight to rear suspension) | mm | 3340 | |||
Width | 1640 | |||||
High (to muffler) | 1820 | |||||
Wheelbase | 1855 | |||||
Size track | Front wheel | 1073-1257 | ||||
Rear wheel | 960-1460 | |||||
Ground clearance | Minimum ground clearance | 330(Drain plug at the front axle) | ||||
Agricultural gap | 400(The lower end surface of the axle housing of the front axle) | |||||
Turning circle radius | Unilateral braking | m | 2.7±0.20/2.85±0.20 | |||
Not unilateral braking | 3.0±0.30/3.15±0.30 | |||||
Structural quality | kg | 1375 | ||||
Minimum use quality | 1537 | |||||
Mass distribution | Front wheel | 707 | ||||
Rear wheel | 830 | |||||
Counterweight (optional) | Front counterweight | |||||
Rear counterweight | ||||||
Walking system | Tire specifications | Front wheel | 6.00-16、6.50-16/7.5-16 | |||
Rear wheel | 9.5-24/11.20-24/12.40-24 | |||||
Tire pressure | Front wheel | kpa | 200-250 | |||
Rear wheel | 120-200 | |||||
Working equipment | Suspension mechanism | Rear three-point suspension, category 1 | ||||
Tillage adjustment method | Position control and floating control | |||||
Lifting force (frame) | kN | 7.5 | ||||
PTO shaft | Type | Rear, non-independent | ||||
Rotating speed | r/mim | 540/720(optional540/1000) | ||||
Output shaft head specifications | θ35X6Key rectangular spline(optionalθ35X8Key rectangular spline) | |||||
Perfusion volume | Heat sink | L(liter) | 10 | |||
Fuel tank | 29 | |||||
Engine oil pan | 5 | |||||
Gearbox oil | 20 | |||||
Lifter oil | 9.5 | |||||
Front drive axle | 6 |
