Truck Body Details

Truck Body
Key Features
Cold King Refrigerator Truck is made of all-closed sandwich structure panels, which is made by special technology to vacuum form
complete panels. We use free-Freon molding polyurethane foam as inner insulation materials. The internal and external coverings
are integral FRP sheets (fiberglass reinforced polyester), therefore, homogeneous construction (without any metallic
reinforcements).
Truck Body Outer Size
4.3m(L)x2.0m(W)x2.1m(H)
Truck Body Inner Size
4.13m(L)x1.83m(W)x1.89m(H)
Roof/Floor Panel
105mm Thickness
Side Wall Panel
85mm Thickness
Front Wall Panel
85mm Thickness
Rear Door Panel
85mm Thickness
Panel Structure

All Closed Sandwich
Panel Insulation
FRP + PU Foam + FRP
Side Door Quantity

None, Optional
Side Door Location
None, Optional
Side Door Type
Single/Double Opening
Side Door Size
Customized
Rear Door Type
Full Size Double Opening Rear Door, Right Hnad Rear Door Open First

Multi-Temperature
System Type

None, Optional
Front Space Temp.
-25C
Rear Space Temp.
-25C
Partition Wall Panel
None
Partition Wall Door
None
Multi-Temperature Pressure Relief Ventilation
None
Mulit-Temperature Adjusting Ventilation System
None
Truck Body Flooring
Heavy Duty Aluminum Alloy T Type Airflow Flooring
Cargo Control System
None, Optional
Ceiling Light
2 (Two) Sets of 12/24V Multi-Voltage LED

Marker Light
2 Sets Of White LED On Front;
2 Sets Of Red LED On Rear
Ceiling Light Switch
1 (One) Set of Automatic Time-Delayed 12/24V Multi-Voltage Switch
Insulating Curtain
European Standard -40C PVC Strip Curtain System For Rear Doors
Refrigeration Unit Service Ladder
Stainless Steel
Refrigeration Unit Service Platform
None, Optional
Airflow Flooring
Heavy Duty Aluminum Alloy T Type Airflow Flooring
Rear Door Assembly
Stainles Steel Rear Door Frame With Stainless Steel Lock Sets & Stainless Steel Hinges.
Refrigeration Unit
Refrigeration Unit Brand
ATOP
Refrigeration Unit Model
AT-KLC430
Refrigeration Unit Type
Truck Engine Driven, Split
Refrigerant
HFC R404a
Airflow Volume
1,600m3/h
Refrigeration Capacity
(+30C Ambient/Road )
2,000W (@ -18C)
3,300W (@ 0C)
Refrigeration Capacity
(+30C Ambient/Standby)
Available Optional
Defrost
Automatic Hot Gas
Compressor
Number of Cylinders
6
Max. Recommended Speed
2,400rpm
Model/Type
5H16 Swash Plate Type
Displacement
162cc
Optional Items
Hydraulic Tail Lift
Aluminium Alloy/Steel Platform Hydraulic Tail Lift Are Available
Cargo Control System
Smart & customized cargo Loading control system
Meat Hanging System
Heavy duty stainless steel meat hook & aluminum alloy rail for rapid & stable meat transportation
Roll carts
Roll carts for rapid and efficient loading, delivery and unloading goods. It was customized made according to inner dimension &
configuration of refrigeration truck body.
Multi-Temperature Partition
Multi-temperature purpose longitudinally moveable, insulated transverse partition wall
