Manufacturer Price Large Turntable Slewing Bearing Slewing Ring
US $900.00-$920.00
Высокоскоростной подшипник SKF 6204-2Z/C3 шариковый с глубоким
- Категории: Bearings >>>
- Поставщик: Shandong,Huafei,Bearing,Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
High speed SKF bearing6204-2Z/C3 Deep Groove Ball Bearing 6204-2Z/C3 bearing SKF
Before your order online, contact me for more discount please!
Products Description
Deep groove ball bearing Types:
1 , single row deep groove ball bearings
2 , with a dust cover single row deep groove ball bearings
3 , with a dust cover , a ring of single row deep groove ball bearings
4, the stopper grooves and snap ring of single row deep groove ball bearing outer ring
5 , ball gap deep groove ball bearings
6 , double row deep groove ball bearings
According to the sizes of deep groove ball bearings can be divided into :
( 1 ) miniature bearings ---- nominal diameter size range of 26mm below the bearing ;
( 2 ) small bearings ---- nominal diameter size range of 28-55mm bearings ;
( 3 ) small and medium sized bearing ---- nominal diameter size range of 60-115mm bearings ;
( 4) large bearing ---- nominal diameter size range of 120-190mm bearing
( 5 ) Large bearing ---- nominal diameter size range of 200-430mm bearings ;
( 6 ) large bearings ---- nominal diameter size range of 440mm or more bearings.
Deep groove ball Applications:
Deep groove ball bearings can be used for transmission, instrumentation, motors, appliances, internal combustion engines, transportation vehicles, agricultural machinery, construction machinery, engineering machinery , roller skate style , yo-yo , precision instruments, low noise motors, automobiles , motorcycles vehicles.
1 , single row deep groove ball bearings
2 , with a dust cover single row deep groove ball bearings
3 , with a dust cover , a ring of single row deep groove ball bearings
4, the stopper grooves and snap ring of single row deep groove ball bearing outer ring
5 , ball gap deep groove ball bearings
6 , double row deep groove ball bearings
According to the sizes of deep groove ball bearings can be divided into :
( 1 ) miniature bearings ---- nominal diameter size range of 26mm below the bearing ;
( 2 ) small bearings ---- nominal diameter size range of 28-55mm bearings ;
( 3 ) small and medium sized bearing ---- nominal diameter size range of 60-115mm bearings ;
( 4) large bearing ---- nominal diameter size range of 120-190mm bearing
( 5 ) Large bearing ---- nominal diameter size range of 200-430mm bearings ;
( 6 ) large bearings ---- nominal diameter size range of 440mm or more bearings.
Deep groove ball Applications:
Deep groove ball bearings can be used for transmission, instrumentation, motors, appliances, internal combustion engines, transportation vehicles, agricultural machinery, construction machinery, engineering machinery , roller skate style , yo-yo , precision instruments, low noise motors, automobiles , motorcycles vehicles.
Product Name | SKF Deep Groove Ball Bearing |
Model Number | 6204-2Z/C3 bearing |
Inner Diameter | 20mm |
Outer Diameter | 47mm |
Breadth | 14mm |
Weight | 0.11KG |
Product Material | Chrome steel |
Precision Grade | P0 P6 P5 P4 P2 are all available |
Cage Material | steel , brass , nylon |
Serive | Agent, OEM ,customized |
Delivery Time | Generally it is 2-5 datys if in stock,7-15 days if not stock,or it is according to customer's requirements |
Features | Long life and high quality |
High precision , low noise with strict controling of the quality | |
High loading by the advanced high-technical design | |
Most competitive price , factory direct | |
OEM service offered ,to meet the customer's requrements | |
Price Terms | EXW, FOB, CFR, CIF |
Package | PE bag+paper box+outer carton+wooden box+pallet, or as customers' requirement |
Details Images
Related product:
Angular Contact Ball Bearings
Cylindrical Roller Bearings
Taper Roller Bearings
Spherical Roller Bearings
For more detailed pictures, please contact me.
Angular Contact Ball Bearings
Cylindrical Roller Bearings
Taper Roller Bearings
Spherical Roller Bearings
For more detailed pictures, please contact me.
SKF bearing 6204-2Z/C3 Deep Groove Ball Bearing 6204-2Z/C3 bearing SKF
Designation | Principal dimensions | Basic load ratings | Speed ratings | ||||||||
dynamic | static | Reference speed | Limiting speed | ||||||||
d[mm] | D[mm] | B[mm] | C[kN] | C0[kN] | [r/min] | [r/min] | |||||
4204 ATN9 | 20 | 47 | 18 | 17.8 | 12.5 | 24 000 | 13 000 | ||||
4304 ATN9 | 20 | 52 | 21 | 23.4 | 16 | 22 000 | 12 000 | ||||
6004 | 20 | 42 | 12 | 9.95 | 5 | 38 000 | 24 000 | ||||
6004 NR | 20 | 42 | 12 | 9.95 | 5 | 38 000 | 24 000 | ||||
6004-2RSH | 20 | 42 | 12 | 9.95 | 5 | 11 000 | |||||
6004-2RSL | 20 | 42 | 12 | 9.95 | 5 | 38 000 | 19 000 | ||||
6004-2Z | 20 | 42 | 12 | 9.95 | 5 | 38 000 | 19 000 | ||||
6004-2ZNR | 20 | 42 | 12 | 9.95 | 5 | 38 000 | 19 000 | ||||
6004-RSH | 20 | 42 | 12 | 9.95 | 5 | 11 000 | |||||
6004-RSL | 20 | 42 | 12 | 9.95 | 5 | 38 000 | 19 000 | ||||
61804 | 20 | 32 | 7 | 4.03 | 2.32 | 45 000 | 28 000 | ||||
61804-2RS1 | 20 | 32 | 7 | 4.03 | 2.32 | 13 000 | |||||
61804-2RZ | 20 | 32 | 7 | 4.03 | 2.32 | 45 000 | 22 000 | ||||
61904 | 20 | 37 | 9 | 6.37 | 3.65 | 43 000 | 26 000 | ||||
61904-2RS1 | 20 | 37 | 9 | 6.37 | 3.65 | 12 000 | |||||
61904-2RZ | 20 | 37 | 9 | 6.37 | 3.65 | 43 000 | 20 000 | ||||
6204 | 20 | 47 | 14 | 13.5 | 6.55 | 32 000 | 20 000 | ||||
6204 ETN9 | 20 | 47 | 14 | 15.6 | 7.65 | 32 000 | 20 000 | ||||
6204 N | 20 | 47 | 14 | 13.5 | 6.55 | 32 000 | 20 000 | ||||
6204 NR | 20 | 47 | 14 | 13.5 | 6.55 | 32 000 | 20 000 | ||||
6204-2RSH | 20 | 47 | 14 | 13.5 | 6.55 | 10 000 | |||||
6204-2RSL | 20 | 47 | 14 | 13.5 | 6.55 | 32 000 | 17 000 | ||||
6204-2Z | 20 | 47 | 14 | 13.5 | 6.55 | 32 000 | 17 000 | ||||
6204-2ZNR | 20 | 47 | 14 | 13.5 | 6.55 | 32 000 | 17 000 | ||||
6204-RSH | 20 | 47 | 14 | 13.5 | 6.55 | 10 000 | |||||
6204-Z | 20 | 47 | 14 | 13.5 | 6.55 | 32 000 | 20 000 | ||||
6204-ZNR | 20 | 47 | 14 | 13.5 | 6.55 | 32 000 | 20 000 | ||||
62204-2RS1 | 20 | 47 | 18 | 12.7 | 6.55 | 10 000 | |||||
62304-2RS1 | 20 | 52 | 21 | 15.9 | 7.8 | 9 500 | |||||
6304 | 20 | 52 | 15 | 16.8 | 7.8 | 30 000 | 19 000 | ||||
Ps: This is part model number of deep groove ball bearings we have, if you are fail to find the one you need, please contact us directly
