DP58U-02 58mm desk USB Thermal Receipt Printer | ||
Printing Method | Direct Thermal Printing | |
Effective Printing Width | 48mm | |
Resolution | 203dpi | |
Printing Speed | Max.90mm/s | |
Printing density | 384 dots/line | |
Line space | 3.75mm(adjustable) | |
Character set | GB18030(Simplified Chinese) and codepage | |
Print font | ASCII Font A:12×24 | |
ASCII Font B:9×17 | ||
Chinese: 24×24 | ||
Character per line | Font A-32 lines/Font B-42 lines/Chinese-16 lines | |
Paper Type | Thermal paper | |
Paper Width | 57.5±0.5mm | |
Paper Roll Diameter | Φ65mm | |
Paper loading | Easy paper loading | |
Paper out detection | Support | |
MCBF(MCBF) | null | |
Auto cutter | null | |
Printer Head Life | 50km Printing length | |
Barcode type | UPC-A,UPC-E,EAN-13,EAN-8,CODE39,ITF,CODEBAR,CODE93,CODE128 | |
Interface | USB + RJ11 for cash drawer | |
printing command | ESC/POS | |
Driver | WIN2003/WINXP/WIN7/WIN8/WIN10/LINUX/MAC | |
Input Power | DC 12V,3A | |
Cash box control | DC 12V,1A | |
Weight | 1.1kg | |
Printer Dimension(WxLxH) | 180×130×105mm | |
Working Environment | temperature:0~45℃ | |
humidity: 20-90% | ||
Storage Environment | temperature:-10~60℃ | |
humidity: 10-90%(paper exclused) | ||
Application | Restaurants, Department Stores, Kitchen, Convenience Stores, | |
Specialty Retail, Super market |
