Гидравлический Наклонный вакуумный меситель из нержавеющей

Описание и отзывы

Характеристики

    Mainly used in offset printing ink ,silicom  rubber,plastic,pencils,heat-shrinkable material,paints,mosquito coils,carbon graphite,oil,gum base,various viscosity of CMC,modified starch,BMC ,SMC,composit manhole cover,pharmaceuticals industry etc.Agitator and the part contactwith material is made of stainless steel,which could corrosion-resistant and non-rust,also ensure the material chemical properies. Bearing support uses self-aligning bearing with the feature of no movement along shaft.

Type	Volume/L	Electrical power/kw	Power/kw	Steam/Mpa	Speed/rpm
NHL-5L	5	0.75-1.5	0.15	0.3	N1=59,N2=35
NHL-40L	40	2.2-5.5	3	0.3	N1=59,N2=35
NHL-100L	100	4-11	4	0.3	N1=40,N2=21
NHL-300L	300	11-22	8	0.3	N1=40,N2=21
NHL-500L	500	15-30	16	0.3	N1=36,N2=21
NHL-1000L	1000	18.5-55	24	0.3	N1=33,N2=22
NHL-1500L	1500	22-55	36	0.3	N1=38,N2=21
NHL-2000L	2000	37-75	48	0.3	N1=25,N2=17
NHL-3000L	3000	45-90	60	0.3	N1=25,N2=18
NHL-4000L	4000	55-110	66	0.3	N1=33,N2=20
NHL-5000L	5000	90-132		0.3	N1=36,N2=21
