Машина для производства пластиковых резервуаров для воды Juneng
US $35000-$38000
5-12L Экструзионная выдувная формовочная машина для производства пластиковых бутылок jerrycan выдувное
- Категории: Extrusion Blow Molding Machines >>>
- Поставщик: Taizhou,Huangyan,Juneng,Machine,&,Mould,Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
12 Liter Plastics Blow Moulding Machine
5L 2cavities 10-12L 1cavity
lubricant bottles, lotion and shampoo bottles, detergent bottle, watering can...
| Max. Product Volume | L | JN-2S12L |
| Dry cycle | PC/H | 600 |
| Screw diameter | MM | 90 |
| screw L/D ratio | L/D | 24-26 |
| screw motor power | KW | 37-45 |
| screw heating capacity | KW | 7.3-9 |
| No. of heating zone | Zone | 4 |
| output of HDPE | KG/H | 120-130 |
| oil pump driver power | KW | 22 |
| clamping force | KN | 120 |
| mold stroke | MM | 180-600 |
| size of mold(W*H) | MM | 450*500 |
| Moving distance | MM | 550 |
| Max. Die diameter(W*H) | MM | 220 |
| Die heat capacity | KW | 4.5-5.5 |
| Blowing pressure | MPA | 0.6-0.8 |
| Air volume | M3/Min | 0.8 |
| Cooling water pressure | MPA | 0.5 |
| water consumption | L/Min | 70 |
| weight of machine | Ton | 11.2 |
| size of machine | M | 3.5*3.5*2.6 |
