Машина для прокатки листового металла
US $10000
XHH KLS25-220-530 оцинкованный кровельный лист делая панель Портативный Профилегибочная стоячий фальц машины для
- Категории: Tile Making Machinery >>>
- Поставщик: Xiamen,Xinhonghua,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
Product Description
XHH KLS25-220-530 Galvanized Roofing Metal Sheet Making Panel Portable Roll Forming Standing Seam Machine For Sale
| Size | YX65-400/425 | KLS25-220-530 |
| Dimension | 5800*1600*1500mm | 2000*1300*1400mm |
| Weight | 7000KGS | 1200KGS |
| Motor Power | 7.5KW*2 | 1.5KW |
| Hydraulic Power | 2.2KW | 0.75kw |
| Voltage | 380V/50HZ/3PH | 380V/50HZ/3PH |
| Forming Steps | 13 steps | 6 steps |
| Forming Speed | 8-15m/min | 8-12m/min |
| Effective Width | 400mm,425mm | 220-530mm |
| Material of Width | 575mm,600mm | 290mm-600mm |
| Material of AL-Mg-Mn, Galvanized Sheet Thickness | 0.7-1.0mm | 0.4-1.0mm |
| Q235 Steel Sheet Thickness | 0.5-0.8mm | 0.5-0.8mm |
| Standing Height of Roofing | 65mm | 25mm |
| Thickness for common use and testing machine | 0.6mm, 0.7mm (material: PPGI, GI, Aluminum) | 0.6mm, 0.7mm (material: PPGI, GI, Aluminum) |
Main Accessories:
- Main Seamlock Roofing Forming Machine;
- Main uncoiler;
- Hydraulic System;
- PLC Computer Controlling System With Touch Screen;
- Hydraulic Forming Cutter;
- Tools;
- Operation Manual.
