CE /ISO approved custom voltage/color/LOGO machine factory China Highway Markline Shot Blasting Machine/Abrator/Blaster
Product Description
Work Introduction
The pill material stored in the lower part of the separation tank by the feed tube into the shot blasting parts, shot blast wheel at high speed rolation by blasting machine motor, the pill is accelarate to accelerate to 80m/s clean the surface, high-speed energy pills material impact work surface. Under negative pressure pills materials and dust back to the dust separation box, where they completed the separation of pill material and dust and impurities, good pill
material into the shot blasting parts continue to use, dust and impurities are filtered slip to closed set dust box waiting to be processed.
Specification
Application of Floor/Movable Shot Blasting Machine
1）Industrial floor coating and processing
2）Mark line processing
3）The airport line cleaning / Airport runway plastic remove
4）Steel plate and steel structure surface clean treatment and rust remove
5）Concrete bridge surface treatment
6）Road surface anti-skid treatment, Water seepage treatment
7）Bridge nursing
8）The highway project conservation
9）The hull surface maintenance rust removing
10）Storage tanks conservation remove rust and paint
11）Epoxy resin floor clean
12）Conservation of other surface treatment
2）Mark line processing
3）The airport line cleaning / Airport runway plastic remove
4）Steel plate and steel structure surface clean treatment and rust remove
5）Concrete bridge surface treatment
6）Road surface anti-skid treatment, Water seepage treatment
7）Bridge nursing
8）The highway project conservation
9）The hull surface maintenance rust removing
10）Storage tanks conservation remove rust and paint
11）Epoxy resin floor clean
12）Conservation of other surface treatment
Technique Parameter
♦ Diameter of shot blasting wheel:200mm
♦ Working width:800mm
♦ Concrete surface cleaning efficiency:
♦ Working width:800mm
♦ Concrete surface cleaning efficiency:
≥600㎡/h
♦ Steel plate cleaning efficiency: 100-160㎡/h
(Depends on the corrosion of the steel plate)
♦ Dust removal pipe diameter: 150mm
♦ Pill diameter: 1.5-1.8mm
♦ Consumption of pill: 10g/㎡
♦ Motor power: 2*11Kw
♦ Weight: 700kg
♦ Walking speed: 0.5-33 m/h
♦ Dimensions:1950*1020*1050mm
♦ Steel plate cleaning efficiency: 100-160㎡/h
(Depends on the corrosion of the steel plate)
♦ Dust removal pipe diameter: 150mm
♦ Pill diameter: 1.5-1.8mm
♦ Consumption of pill: 10g/㎡
♦ Motor power: 2*11Kw
♦ Weight: 700kg
♦ Walking speed: 0.5-33 m/h
♦ Dimensions:1950*1020*1050mm
Dust collector： ROFC-11 11 Filter Automatic vacuum cleaner ♦ Motor power: 7.5Kw ♦ Air flow: 3500 ㎡/h ♦ Clean manner: Auto Reverse Blow ♦ Filter surface: 48㎡ ♦ Ash bucket capacity：140L ♦ Dimensions: 2100*1300*1700mm ♦ Weight: 930kg | ||||||||
Packing & Delivery
Company Profile
Company profile
Rovan Machinery Co., Ltd. was established in 2001, intergrated scientific research, design, manufacture, debugging installation consulting service professional equipment manufacture enterprises.
The company has always been adhering to the ‘win-win’ business purposes, to provide customers with quality products and services while focusing on self-construction, introduced ISO9001 quality management system, and built a 100 highly qualified employee to be strong backing.
The company mainly produces dustless blasting and shot blasting machine, the products are mainly for shipbuilding, the tire manufacture and the road shot blasting machine, mobile shot blasting machine and other special equipment.
The company mainly produces dustless blasting and shot blasting machine, the products are mainly for shipbuilding, the tire manufacture and the road shot blasting machine, mobile shot blasting machine and other special equipment.
