YTO 300P колесный трактор ISO 2WD силовой культиватор
- Категории: Tractors >>>
- Поставщик: Maxizm,Construction,Machinery,(Qingdao),Co.,Ltd.
Поделиться:
Описание и отзывы
Характеристики
YTO 240HP Wheel Tractor ZH1125E2 ISO mini tractor trailer for sale
Contact us
Hana Che
Sales Director
Whatsapp/Wechat/Mobile: +86 17854169033
Maxizm Construction Machinery (Qingdao) Co., Ltd.
Tel: +86 053285796888-8011
Whatsapp/Wechat/Mobile: +86 17854169033
Maxizm Construction Machinery (Qingdao) Co., Ltd.
Tel: +86 053285796888-8011
Web:https: //www.maxizm.com/
Facebook: https://www.facebook.com/profile.php?id=100068562252811
Facebook: https://www.facebook.com/profile.php?id=100068562252811
Products Description
1. YTO-240P/300P/350P Wheeled Tractor
(1) Compact structure and high reliability, ease of operation and maintenance;
(2) Equipped with famous engines, energy saving and environmental protection;
(3) Suitable for operations on small land areas and driving on narrow roads
2. YTO-SK244 Wheeled Tractor
(1) This range of product is installed with 3-cylinder diesel actuated by electricity
(2) Compared with tractor of the same horsepower, this product features light weight, small volume, simple structure, and high
cost performance.
(1) Compact structure and high reliability, ease of operation and maintenance;
(2) Equipped with famous engines, energy saving and environmental protection;
(3) Suitable for operations on small land areas and driving on narrow roads
2. YTO-SK244 Wheeled Tractor
(1) This range of product is installed with 3-cylinder diesel actuated by electricity
(2) Compared with tractor of the same horsepower, this product features light weight, small volume, simple structure, and high
cost performance.
Product Paramenters
Model | YTO-240P | YTO-300P | YTO-350P | YTO-SK244 | ||||
Diesel engine | ||||||||
Model | ZH1125E2 | ZH1130E2 | ZH1135E2 | YD385T | ||||
Type | Single cylinder, horizontal, water cooled, four stroke | Double cylinder, vertical, water cooled, four stroke | ||||||
Displacement (L) | 1.47 | 1.59 | 1.93 | 1.53 | ||||
Rated power/speed(Kw)/(r/min) | 17.7/2200 | 22.1/2200 | 25.7/2300 | 17.7/2350 | ||||
Max. torque (N.m)/speed (r/min) | 78.61/1760 | 98.3/1760 | 116/1760 | 83/1700 | ||||
Bore x stroke (mm) | 125 X 120 | 130 X 120 | 135 X 135 | 85×90 | ||||
Transmission | ||||||||
Gear shift, forward/backward | 8/2 | 8/2 | 8/2 | 8/2 | ||||
Speed range (Km/h), forward/backward | 3.17-32.7/4.2-11.8 | 3.17-32.7/4.2-11.8 | 3.17-32.7/4.2-11.8 | 2.07-31.54/2.72-12.59 | ||||
PTO power (Kw) | 15.05 | 18.79 | 21.85 | 15.05 | ||||
PTO rotation speed(r/min) | 540 | 540 | 540 | 540/1000 | ||||
Clutch | Single disc | Single disc | Single disc | Single action (Double action optional) | ||||
Implement | ||||||||
Three-point linkage category | Rear three-point linkage 0 | Rear three-point linkage 0 | Rear three-point linkage 0 | Rear three-point suspension I | ||||
Tilling depth control mode | Floating adjustment | Floating adjustment | Floating adjustment | Height adjustment, position adjustment | ||||
Lifting force(KN) | 4 | 4 | 4 | 4 | ||||
Dimensions, mass, drive | ||||||||
Drive type | 4×2 | 4×2 | 4×2 | 4×4 | ||||
Overall dimensions (LxWxH)(mm) | 2700*1250*1335 | 2700*1250*1335 | 2700*1250*1335 | 3453×1465×1835 | ||||
Wheelbase(mm) | 1400 | 1400 | 1400 | 1698 | ||||
Min. ground clearance(mm) | 320 | 320 | 320 | 260 | ||||
Min. operating mass(with safety stand)(Kg) | 1100 | 1120 | 1150 | 1450 | ||||
Tyre spec., front /rear | 5.0-16/9.5-24 | 5.0-16/9.5-24 | 5.0-16/9.5-24 | 6.0-16/9.5-24 | ||||
Wheel tread, front/rear | 900/1020 | 900/1020 | 900/1020 | 1190/1100-1300 | ||||
Steering | Mechanical | Hydraulic steering | ||||||
Brake | Shoe, mechanical | - | ||||||
